Reznor UDBS-300-AC2-AK1
Reznor UDBS-300-AC2-AK1
Hover to zoom
1 Of 5

Model:

UDBS-300-AC2-AK1

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Model: UDBS-300-AC2-AK1
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Reznor UDBS-300-AC2-AK1 High Static Gas Fired Unit Heater is a 115 volt, gas fired high static unit heater designed to provide efficient heating. Reznor UDBS-300-AC2-AK1 is certified for commercial and industrial use to provide a 300000 BTU/hr. output with an 82-83% thermal efficiency. Vibration isolated venter motors reduce operating noise. UDBS-300-AC2-AK1 provides a 45-75 F rise range. UDBS models use an integrated circuit board with diagnostic indicator lights to control heater operation. External gas connection allows for easy gas service connection. Reznor UDBS-300-AC2-AK1 is designed to be suspended from 4 suspension points. UDBS-300-AC2-AK1 provides improved efficiency and easier installation over previous Reznor models.
  • Reznor UDBS-300-AC2-AK1 Features
  • Certified for commercial/industrial heating
  • Titanium stabilized stainless heat exchanger
  • Multi-try direct spark ignition with 100% lockout
  • Vibration isolated venter motors
  • 4-pt suspension
  • Adjustable belt drive blower
  • Product Note
    The image may not reflect actual product features. The Reznor UDBS-300 comes with ten horizontal louvers.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

UDBS-300-AC2-AK1
specs product image PID-47334
General Information
Product Line
UDBS
Heat Exchanger Material
Stainless Steel
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Horizontal
Mount Type
Suspended
Additional Model Numbers

UDBS-300-AC2-AK1, UDBS-300-AC2-AK1

Performance
Heating Capacity
249000 BTU
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
300000 BTU
Thermal Efficiency
83 %
Maximum Air Flow
5123 CFM
Minimum Air Flow
3074 CFM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Dimensions
Flue Connection Size
6 Inches
Gas Connection Size
3/4 Inch
Product Height
42 5/8 Inches
Product Width
40 7/8 Inches
Product Depth
63 7/16 Inches
Product Weight
375 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
ANSI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
10 Years
