Pensotti DD20.28DBL Wall Panel Radiator 20"H x 28"L - 5,033 BTU

Pensotti DD20.28DBL Wall Panel Radiator 20"H x 28"L - 5,033 BTU
Our Price
Compare Prices
Shipping Info
Model: DD20.28DBL
(Based on expert analysis, manufacturer ratings and customer reviews)
4.9 out of 54.9 out of 54.9 out of 54.9 out of 54.9 out of 5
Number of Reviews (8)
Write A Review
$242.48
Factory-Direct
Ships in 4-7 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping
Holiday Shipping Schedule
Holiday Schedule -
Height
Width

Factory-Direct
Ships in 4-7 Business Days
Free Shipping
Free Shipping
*We currently CANNOT ship this product to California or any destination outside of the United States
Share
  • Product Description
  • 8
    Reviews
  • 2
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    The Pensotti DD20.28DBL panel radiator provides the perfect combination of comfortable radiant heat with an elegant design. It is extremely versatile and can be used as the primary source of heating, a supplement to a radiant floor system, or as an addition with traditional heating sources. Unlike conventional baseboard radiators, Pensotti panel radiators emit both radiant and convective heat to achieve unsurpassed comfort and efficiency. A standard feature on each radiator is an integral thermostatic valve with flow setter. When synthesized with a non-electric operator (optional), automatic room by room temperature control is reached, resulting in further comfort and efficiency. Their durability and ease of service and install make them among the most unique panel radiators.
  • Pensotti DD20.28DBL Features
  • Compact design
  • Uses almost 1/4th the space of traditional radiators
  • Quiet, comfortable heating
  • Eliminates the noises associated with other types of heating systems
  • Efficient heat transfer
  • Radiators emit both radiant and convective heat
  • Scratch, dent and corrosion resistant
  • Reduces cleaning and servicing to a minimal
  • Integral thermostatic valve with flow setter
  • Allows for room by room temperature control
  • Available in a variety of height and widths
  • More flexibility is allowed in room design and furniture placement
Specifications
General Information
Type
Panel
Product Line
DD
Medium ? Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Connection Type
BSP
Material
Steel
Performance
Heating Capacity
5033 BTU
Nominal Heating Capacity
5000 BTU
Dimensions
Supply Connection
1/2 Inch
Return Connection
1/2 Inch
Product Height
20 Inches
Product Width
28 Inches
Product Depth
4 Inches
Product Weight
46 Pounds
Certifications
Country of Origin
Turkey
Warranty Information
Warranty ? A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Years
Features
Features
    The Pensotti DD20.28DBL panel radiator provides the perfect combination of comfortable radiant heat with an elegant design. It is extremely versatile and can be used as the primary source of heating, a supplement to a radiant floor system, or as an addition with traditional heating sources. Unlike conventional baseboard radiators, Pensotti panel radiators emit both radiant and convective heat to achieve unsurpassed comfort and efficiency. A standard feature on each radiator is an integral thermostatic valve with flow setter. When synthesized with a non-electric operator (optional), automatic room by room temperature control is reached, resulting in further comfort and efficiency. Their durability and ease of service and install make them among the most unique panel radiators.
  • Pensotti DD20.28DBL Features
  • Compact design
  • Uses almost 1/4th the space of traditional radiators
  • Quiet, comfortable heating
  • Eliminates the noises associated with other types of heating systems
  • Efficient heat transfer
  • Radiators emit both radiant and convective heat
  • Scratch, dent and corrosion resistant
  • Reduces cleaning and servicing to a minimal
  • Integral thermostatic valve with flow setter
  • Allows for room by room temperature control
  • Available in a variety of height and widths
  • More flexibility is allowed in room design and furniture placement
Specifications
General Information
Type
Panel
Product Line
DD
Medium ? Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Connection Type
BSP
Material
Steel
Performance
Heating Capacity
5033 BTU
Nominal Heating Capacity
5000 BTU
Dimensions
Supply Connection
1/2 Inch
Return Connection
1/2 Inch
Product Height
20 Inches
Product Width
28 Inches
Product Depth
4 Inches
Product Weight
46 Pounds
Certifications
Country of Origin
Turkey
Warranty Information
Warranty ? A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Years
Product Specs
+
Specifications
General Information
Type
Panel
Product Line
DD
Medium ? Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Connection Type
BSP
Material
Steel
Performance
Heating Capacity
5033 BTU
Nominal Heating Capacity
5000 BTU
Dimensions
Supply Connection
1/2 Inch
Return Connection
1/2 Inch
Product Height
20 Inches
Product Width
28 Inches
Product Depth
4 Inches
Product Weight
46 Pounds
Certifications
Country of Origin
Turkey
Warranty Information
Warranty ? A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Years
Reviews
(8)
+
Pensotti DD20.28DBL Reviews & Ratings
Product Q&A
(2)
+
Search Product Q&A's Answered by Chris, the eComfort Product Expert
icon-social-fb1
+
Can this be used to replace regular baseboard in a low pressure boiler system of 18 - 22 psi?
Mark
from New York
March 16, 2016
Answer
Assuming you are referring to a hot water rather than a steam system, the pressures you quoted are quite typical for the types of systems the Pensotti radiator is designed to be used in.
+
I just installed this radiator in our basement. It is on a single loop system and is the coldest room in the house. When the boiler is on, I would like this radiator to get as hot as possible. Can you explain how to adjust the integral thermostatic and flow setter valve? Mine has a white plastic adjuster. Do I just open it until it stops?
Jason
from Pennsylvania
December 23, 2015
Answer
The flow regulating valve has two different means of adjustment. The primary flow control is the white knob that you describe. When this knob is fully unscrewed, the valve allows full flow through the radiator. As the knob is tightened, it gradually reduces the flow.

Underneath the knob is a dial numbered 1 to 6. This dial controls the maximum flow through the radiator. Align the number 6 with the slot in the valve body to allow the maximum flow. Details can be found in the installation manual on page 17.
