Oxbox J4AHP - 2.0 Ton - Air Handler - Multi-Position - PSC Motor



Write A Review
Free Shipping
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Ships in 2-5 Business Days
synchrony card logo
$146 / Month
Suggested monthly payments with 6 month financing.
Oxbox J4AHP - 2.0 Ton - Air Handler - Multi-Position - PSC Motor
Oxbox J4AHP - 2.0 Ton - Air Handler - Multi-Position - PSC Motor
Model: J4AH4P24B1B00AA
Product Q&A
How-To Articles

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Chris, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10


    The Oxbox air handler is designed to supplement your air conditioner or heat pump by circulating cooled or heated air throughout your home. The air handler offers flexible installation options with its multi-position airflow design. An all-aluminum coil provides efficient heat transfer while its painted galvanized steel cabinet resist rust over years of use.
  • All-aluminum Coil
  • The Oxbox air handler includes an all-aluminum coil for advanced heat transfer and efficiency.
  • Durable Cabinet
  • Oxbox air handlers include a painted, galvanized steel cabinet to resist rust and retain peak efficiency.
  • Dual Drainage
  • For increased installation flexibility, the Oxbox air handler features two drainage spouts.
  • Easy Access
  • Oxbox air handlers feature removable front panel and blower and coil assemblies for simple maintenance and troubleshooting.
  • Product Note
  • In order to maintain the warranty, product must be installed by a licensed contractor. Proof of installation by a licensed contractor is required.
California residents see
Warning: This product can expose you to chemicals including Lead and lead compounds which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov


specs product image PID-110386
General Information
Air Handler
Product Line
Refrigerant Type
Blower Motor
Motor Type
Configuration Learn More
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Installation Location
Additional Model Numbers

J4AH4P24A1B00AA, J4AH4P24B1B00AA

Capacity Learn More
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
2.0 Tons
Cooling BTU
Maximum Air Flow
1107 CFM
Minimum Air Flow
190 CFM
Electrical Data
208/230 Volts
60 Hz
Suction Connection Size
3/4 Inch
Liquid Connection Size
3/8 Inch
Product Height
46 1/2 Inches
Product Width
19 5/8 Inches
Product Depth
21 5/8 Inches
Product Weight
125 Pounds
Shipping Height
47 19/24 Inches
Shipping Width
22 29/48 Inches
Shipping Length
25 17/24 Inches
Shipping Weight
141 Pounds
ETL Listed
AHRI Certified
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
