Fantech Flex - 106 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 5" Duct - Recirculation

Fantech Flex - 106 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 5" Duct - Recirculation
Model: FLEX100H
Product Discontinued
Sorry, this product is no longer available.
Discontinued

(as of 09:22 CST - Details) Sales Tax Extra $629.00Visit Site
Discontinued
Sorry, this product is no longer available
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Free Shipping
Free Shipping
  • Product Description
  • Reviews
  • 2
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features

    The Fantech FLEX 100H Heat Recovery Ventilator (HRV) is a 106 CFM heat recovery ventilator with top ports and recirculation defrost capabilities. The FLEX 100H is a 120 volt unit designed with 4 ports with 5" ducts. It is designed for applications in town houses, condominiums, and apartment buildings. HRVs make your heating and cooling systems more efficient by transferring heat between fresh and stale air during ventilation. 10% smaller than comparable units, the Flex 100H HRV provides up to 50% more exhaust capacity. It is constructed with noise reducing fans and a built-in TurboTouch feature that boosts capacity 50%.

    Product Features

    Heat Recovery Core
    An aluminum heat recovery core provides improved heat transfer capacity while taking up less space than traditional cores.

    Winter Guard
    A built-in recirculating defrost system allows for consistent, reliable operation during the winter months.

    Compact Flexible Installation
    10% smaller and 5% lighter than comparable units, the Flex 100H is among the smallest HRVs in its category. "&"The Flex 100H is includes and is easily installed with an EZ-Mount wall bracket.

    Quiet Operation
    Top of the line technology dramatically reduces noise during operation.

    TurboTouch
    The TurboTouch feature provides up to 50% more exhaust capacity.

    Simple Installation
    The EZ-Mount wall bracket allows easy installation by just one person.

    Easy Maintenance
    All serviceable components are easily accessible in under 5 minutes.

    Product Includes
    • (1) FLEX 100H Heat Recovery Ventilator (HRV)
    • (1) Mounting Chains
Specifications
General Information
Type
HRV
Product Line
Flex
Defrost Type ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Ports Quantity
4
Port Location
Top
UPC
650737440015
Performance
Sensible Recovery Efficiency
70 %
Apparent Sensible Effectiveness
80 %
Minimum Air Flow
50 CFM
Maximum Air Flow
106 CFM
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Condensate Drain Size
0.5 Inches
Duct Connection
5 Inches
Product Height
17.9 Inches
Product Width
22.4 Inches
Product Depth
15 Inches
Product Weight
39 Pounds
Shipping Height
21 Inches
Shipping Width
17 Inches
Shipping Length
24 Inches
Shipping Weight
39 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
Features
Features

    The Fantech FLEX 100H Heat Recovery Ventilator (HRV) is a 106 CFM heat recovery ventilator with top ports and recirculation defrost capabilities. The FLEX 100H is a 120 volt unit designed with 4 ports with 5" ducts. It is designed for applications in town houses, condominiums, and apartment buildings. HRVs make your heating and cooling systems more efficient by transferring heat between fresh and stale air during ventilation. 10% smaller than comparable units, the Flex 100H HRV provides up to 50% more exhaust capacity. It is constructed with noise reducing fans and a built-in TurboTouch feature that boosts capacity 50%.

    Product Features

    Heat Recovery Core
    An aluminum heat recovery core provides improved heat transfer capacity while taking up less space than traditional cores.

    Winter Guard
    A built-in recirculating defrost system allows for consistent, reliable operation during the winter months.

    Compact Flexible Installation
    10% smaller and 5% lighter than comparable units, the Flex 100H is among the smallest HRVs in its category. "&"The Flex 100H is includes and is easily installed with an EZ-Mount wall bracket.

    Quiet Operation
    Top of the line technology dramatically reduces noise during operation.

    TurboTouch
    The TurboTouch feature provides up to 50% more exhaust capacity.

    Simple Installation
    The EZ-Mount wall bracket allows easy installation by just one person.

    Easy Maintenance
    All serviceable components are easily accessible in under 5 minutes.

    Product Includes
    • (1) FLEX 100H Heat Recovery Ventilator (HRV)
    • (1) Mounting Chains
Specifications
General Information
Type
HRV
Product Line
Flex
Defrost Type ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Ports Quantity
4
Port Location
Top
UPC
650737440015
Performance
Sensible Recovery Efficiency
70 %
Apparent Sensible Effectiveness
80 %
Minimum Air Flow
50 CFM
Maximum Air Flow
106 CFM
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Condensate Drain Size
0.5 Inches
Duct Connection
5 Inches
Product Height
17.9 Inches
Product Width
22.4 Inches
Product Depth
15 Inches
Product Weight
39 Pounds
Shipping Height
21 Inches
Shipping Width
17 Inches
Shipping Length
24 Inches
Shipping Weight
39 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
Product Specs
+
Specifications
General Information
Type
HRV
Product Line
Flex
Defrost Type ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Ports Quantity
4
Port Location
Top
UPC
650737440015
Performance
Sensible Recovery Efficiency
70 %
Apparent Sensible Effectiveness
80 %
Minimum Air Flow
50 CFM
Maximum Air Flow
106 CFM
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Condensate Drain Size
0.5 Inches
Duct Connection
5 Inches
Product Height
17.9 Inches
Product Width
22.4 Inches
Product Depth
15 Inches
Product Weight
39 Pounds
Shipping Height
21 Inches
Shipping Width
17 Inches
Shipping Length
24 Inches
Shipping Weight
39 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
Reviews
+
This product has no reviews.
Be the first to voice your opinion on this Fantech product.
Product Q&A
(2)
+
Will this HRV handle a 2,100 sq. ft. house?
Russell
from New Jersey
March 24, 2016
Read Response +
Answer
Yes, the Fantech FLEX100 should be adequate for a typical application in a 2100 sq. ft. home.
Hide Response -
I'd like to know more about the noise level of this unit (dB). According to the instructions it should not be installed in the living area. I live in a condo and the only place I can put it in would be a closet specially made in the hallway of the condo (midway between the bedrooms and the living room, approximately 15 feet from each). Do I have to sound insulate the closet for it to be silent?
Alex
from New York
March 24, 2016
Read Response +
Answer
HRV units do not have a standard for measuring noise levels so sound levels are not published for these units. Properly installed, I would not expect noise levels to be objectionable.
