Daikin - 18k BTU Cooling + Heating - Aurora Series Concealed Duct Air Conditioning System - 19.4 SEER

Model:

DL18MVJU

Write a Review
$3,377.42
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Factory-Direct
Ships in 4-6 Weeks
synchrony card logo
$60 / Month
With our 86 months 11.99% APR*
86 fixed monthly payments required.
Daikin - 18k BTU Cooling + Heating - Aurora Series Concealed Duct Air Conditioning System - 19.4 SEER
Daikin - 18k BTU Cooling + Heating - Aurora Series Concealed Duct Air Conditioning System - 19.4 SEER
Model: DL18MVJU
$3,377.42
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Chris, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Daikin has firmly established themselves as a world leader in heating and cooling equipment manufacturing, and their ductless systems are no exception. The Aurora Series pairs Daikin's latest in condensing technology with quiet, easy to install, concealed duct indoor units. The Aurora Series outdoor condenser is engineered to provide efficient heating and cooling for your home even in extreme weather conditions while guaranteeing long, reliable, service life. Inside your home, Daikin's concealed duct units offer a simple design meant to blend into any setting. Combined with their standard quiet operation, these units are designed to keep your home comfortable without drawing attention. Advanced filtration technology cleans your home's air at the same time it is conditioned, allowing you and your family to breathe easy without fear of lingering pollutants.
  • Whisper Quiet Operation
  • Daikin ductless units are engineered from the ground up for impressively quiet operation. The solid construction works together with quiet motor operation to make the units as unobtrusive as possible to its surrounding environment.
  • Inverter Technology
  • Daikin's inverter technology works together with the expansion valve to adjust coolant flow and compressor speed to match indoor conditions. This results in less dramatic temperature swings and a more comfortable home.
  • Built-In Advanced Filtration System
  • Daikin mini splits do more for your home's comfort level than control its temperature. An advanced microbial filtration system is installed in the indoor unit, allowing the mini split to purify your home's air as well as heating or cooling it.
  • Included Wireless Control
  • The included wireless control allows you to control the temperature of your room while never leaving the comfort of your favorite recliner.
  • Low Ambient Cooling Capable
  • Daikin condensers continue to provide cooling and heating in low temperature climates. This unit can cool down to an outside temperature of 50F and provide heating down to -13F. With the optional wind baffle, the condenser can cool down to 0F.
  • Product Includes
    • (1) Daikin Aurora - 18k BTU Outdoor Condenser - Single Zone Only (RXL18UMVJU)
    • (1) Daikin Aurora - 18k BTU Concealed Duct Unit - Single Zone Only (FDMQ18RVJU)
    • (1) Daikin Wired Remote Controller for Ceiling Cassette and Concealed Duct Units (BRC1E73)
    Product Note
    This product requires the following accessories for installation:
    • Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
    • Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing.
    • Disconnect Box & Electrical Whip Kit - The Disconnect Box & Whip Kit provides a safe and simple way to connect your outdoor condenser to your fuse box.
    • Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
    • Base Pan Heater - The base pan heater prevents ice from building up on the outdoor unit. Excessive ice build will lead to performance issues and could damage your unit.
    • Outdoor Condenser Plastic Pad or Wall Bracket - We recommend outdoor condensers should not be placed directly on the ground. An outdoor condenser pad or wall bracket will provide a stable way to mount your condenser free from obstructions and debris.
    Adding these accessories to your order will provide a complete, ready-to-install mini split system. All Mini Split Systems require one Primary Mini Split Installation Kit. You may also require one or more Secondary Installation Kits if you have a Multi-Zone system. You will need a Secondary Installation Kit for each additional indoor unit.
California residents see
Warning: This product can expose you to chemicals including Formaldehyde (gas) which is known to the State of California to cause Cancer
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

Product Includes
  • (1) Daikin Aurora - 18k BTU Outdoor Condenser - Single Zone Only (RXL18UMVJU)
  • (1) Daikin Aurora - 18k BTU Concealed Duct Unit - Single Zone Only (FDMQ18RVJU)
  • (1) Daikin Wired Remote Controller for Ceiling Cassette and Concealed Duct Units (BRC1E73)
DL18MVJU
specs product image PID-105139
General Information
Type
Concealed Duct
Product Line
Aurora
Operating Mode Learn More
Heating and Cooling
Number of Zones Learn More
1
Refrigerant Type
R-410A
Indoor Unit Size(s) Learn More
18
Outdoor Unit Size
18000 BTU
DOE Regional Compliance Learn More
Nationwide
Line Set Size
1/4" x 1/2"
Performance
Cooling BTU
18000
Cooling Capacity
17600 BTU
Heating Capacity
21600 BTU
SEER Learn More
19.4
EER Learn More
12.7
HSPF Learn More
10.3
Low Ambient Heating
Yes
Minimum Outdoor Temperature for Heating Learn More
-13 F
Minimum Outdoor Temperature for Cooling
50 F
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Dimensions
Product Weight
212 Pounds
Shipping Weight
217 Pounds
Certifications
AHRI Reference Number
204717991
RXL18UMVJU
General Information
Type
Outdoor Condenser
Product Line
Aurora
Operating Mode Learn More
Heating and Cooling
Maximum Number of Zones
1
Multi-Zone Compatible
No
Refrigerant Type
R-410A
Installation Location
Outdoor
Performance
Cooling BTU
18000
Cooling Capacity
18000 BTU
Minimum Sound Level
54 dB
Maximum Sound Level Learn More
55 dB
Low Ambient Heating
Yes
Minimum Outdoor Temperature for Heating Learn More
-13 F
Minimum Outdoor Temperature for Cooling
50 F
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Dimensions
Maximum Line Length
98.5 Feet
Product Height
28 15/16 Inches
Product Width
34 1/4 Inches
Product Depth
12 5/8 Inches
Product Weight
130 Pounds
Certifications
AHRI Certified
Yes
Warranty Information
Compressor Warranty
7 Years
FDMQ18RVJU
General Information
Type
Concealed Duct
Product Line
Aurora
Operating Mode Learn More
Heating and Cooling
Multi-Zone Compatible
No
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s) Learn More
18
Installation Location
Indoor
Performance
Cooling BTU
18000
Cooling Capacity
18000 BTU
Maximum Air Flow
675 CFM
Minimum Air Flow
473 CFM
Minimum Sound Level
35 dB
Maximum Sound Level Learn More
35 dB
Electrical Data
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
19.8 Amps
Dimensions
Gas Connection Size
1/2 Inch
Liquid Connection Size
1/4 Inch
Condensate Drain Size
1 Inch
Product Height
9 5/8 Inches
Product Width
39 3/8 Inches
Product Depth
31 1/2 Inches
Product Weight
82 Pounds
Certifications
AHRI Certified
Yes
Warranty Information
Parts Warranty Learn More
5 Years
General Information
Type
Mini Split Controller
Voltage Type
Low-Voltage
Programmable
Yes
Power Source
Hardwired
Interface
Buttons
Minimum Setpoint Range
60 F
Maximum Setpoint Range
90 F
Dimensions
Product Height
4 3/4 Inches
Product Width
4 3/4 Inches
Product Depth
3/4 Inch
Shipping Weight
5 Pounds
Warranty Information
Parts Warranty Learn More
5 Years
