We offer the best-selling digital thermostat by combining a single stage, multi-stage and heat pump into one universal thermostat. And better yet we\'ve enhanced it with styling and features specially designed for all systems. It offers more control, more convenience and more value than the competition. And it\'s backed with the reputation of White-Rodgers - pioneers in home comfort since 1937. More Accuracy and Control. If you\'re in the process of upgrading a multi-stage, heat pump or single stage system, don\'t forget the \"brain\" for your new system, your thermostat. Our White-Rodgers 80 Series can maintain a set temperature to within one degree. Plus, there\'s a permanent memory that saves all programs and settings during a power loss. Comfort and Convenience with Versatility. The programmable models deliver perfect comfort, as they automatically change to the temperature you selected for wake-up, during the day, evening hours and while you sleep. You can also configure them with minimum and maximum temperature range for cooling or heating. The lighted display makes for clearer low-light viewing. Maximum Energy Savings. Program heating and cooling times to cut energy use, not comfort. You can save up to 33% in energy costs, depending on your home\'s location, climate and program selections. Now you can have it all, energy savings, with comfort and convenience! See the back to find out how this best-seller gives you more of what you want in a universal thermostat. No Other Thermostat Series Offers More Value for the Money.
White Rodgers 1F80-361 Features
Single Stage
5+1+1 Programmable
Choose between battery powered or hardwired
Fossil fuel or electric heat compatible
Large LCD with backlight
Permanent program retention during power loss
Configuration menu allows keypad selection of options
Specifications
1F80-361
Overview
Product Category
Thermostats and Controls
UPC
786710518812
General Information
Type
Thermostat
Product Category
Thermostats and Controls
Stages
1 Heat/1 Cool
Programmability
5-1-1
System Type
Heating + Cooling
Voltage Type
Low Voltage
Programmable
Yes
Power Source
Hardwire and/or Battery
Internet Connectivity
No
Dimensions
Product Height
3 19/24 Inches
Product Width
6 5/48 Inches
Product Depth
1 5/48 Inches
Warranty Information
Warranty WarrantyA warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Reviews
(5)
White Rodgers 1F80-361 Reviews & Ratings
Customer Photos and Videos
Product Q&A
(3)
Product QuestionsAnswered by Bob, the eComfort Product Expert
1. What voltage does the unit require?
2. Does the unit allow for manual operation of the heating/cooling system? Can it just be set at a "hold" temperature?
Jack
from Kansas
March 02, 2016
Answer
1. This unit is rated for 8 to 30 VAC input.
2. This unit does have a 'HOLD' function, but it is only a temporary hold. It will hold for 3 hours and then revert back to the programmed settings. You could maintain a certain temperature by simply setting each program to the same temperature. Otherwise, there is always the non-programmable option, 1F86-344.
Was this answer helpful?
Yes
1
No
0
What are the dimensions of the thermostat?
Harry
from Texas
November 20, 2015
Answer
The White Rodgers 1F80-361 has the following dimensions: 6.1"W x 3 .8"H x 1.1"D. Thanks for your question!
Was this answer helpful?
Yes
0
No
0
How do I change the battery?
Irene
from Ohio
October 04, 2015
Answer
You will need to remove the thermostat face plate to access to the battery compartment on the base. Please see the manual for details on removing/replacing the batteries.
Was this answer helpful?
Yes
0
No
2
