Weil-McLain Aqua Logic - 18.2 Gal. - Low Profile Indirect Water Heater

Weil-McLain Aqua Logic - 18.2 Gal. - Low Profile Indirect Water Heater
Our Price
Compare Prices
Shipping Info
Model: 633800513
(Based on expert analysis, manufacturer ratings and customer reviews)
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews (2)
Write A Review
$1,432.95
In-Stock
Ships Wednesday, Oct 24th
Free Shipping
Free Lift Gate Service -
Add-Ons

In-Stock
Ships Wednesday, Oct 24th
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • 2
    Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    Adding high efficiency domestic hot water production to a Weil-McLain WM97+ hot water boiler could not be easier than with the Aqua Logic companion water heater. This indirect fired water heater was designed specifically to interface with the WM97+ line, and the wiring harness is preconfigured for a quick plug and play setup. Once set up, the WM97+'s control and display enable additional features for the Aqua Logic, unavailable on traditional indirect fired water heaters. Through the boiler control, users have access to a high production mode, for maximum hot water, and an economy mode, for maximum efficiency. This flexibility means that the Aqua Logic is suited for a variety of applications, including those with shifting hot water requirements. Regardless of application, a three speed Taco circulator and a Honeywell thermostatic mixing valve assure a safe and comfortable temperature of hot water for every fixture.
  • Low Profile
  • The Aqua Logic water heater is designed to slide directly underneath a wall-mounted WM97+ hot water boiler. Space heating and domestic hot water production can be condensed into an attractive column with dimensions of 73.5" H x 25.25" W x 19.3125" D.
  • Programmable Schedule
  • Using the WM97+'s control panel, the Aqua Logic may be set to adhere to a schedule. High demand times such as the early morning may be designated as such without sacrificing efficiency in the afternoon, when less hot water is needed.
  • Product Includes
  • (1) Weil-McLain Aqua Logic Companion Water Heater
  • (1) Honeywell AMX302TLF Thermostatic Mixing Valve
  • (1) Taco Three Speed Circulator
  • (1) 3/4" Temperature and Pressure Valve
  • (1) Drain Valve
  • (2) Flexible Stainless Steel Connection Hoses
  • (1) Preconfigured Wiring harness with Plugs
  • (2) Tank Temperature Sensors
  • (3) Adjustable Leveling legs
  • Product Compatible With
  • Weil-McLain WM97+ Hot Water Boilers
Specifications
General Information
Product Line
WM97 Plus
Fuel Type To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
Single
Connection Type
NPT
Mount Type
Floor
UPC
0672619198388
Performance
Minimum Input Capacity
113000 BTU
First Hour Delivery Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
187 Gallons
Continuous Recovery Rate
172 Gallons
Dimensions
Storage Volume
18.2 Gallons
Cold Water Inlet
0.75 Inches
Hot Water Outlet
0.75 Inches
Supply Connection
1 Inch
Return Connection
1 Inch
Product Height
40.1875 Inches
Product Width
19 Inches
Product Depth
19.3125 Inches
Product Weight
60 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Vessel Warranty
10 Years
Features
Features
    Adding high efficiency domestic hot water production to a Weil-McLain WM97+ hot water boiler could not be easier than with the Aqua Logic companion water heater. This indirect fired water heater was designed specifically to interface with the WM97+ line, and the wiring harness is preconfigured for a quick plug and play setup. Once set up, the WM97+'s control and display enable additional features for the Aqua Logic, unavailable on traditional indirect fired water heaters. Through the boiler control, users have access to a high production mode, for maximum hot water, and an economy mode, for maximum efficiency. This flexibility means that the Aqua Logic is suited for a variety of applications, including those with shifting hot water requirements. Regardless of application, a three speed Taco circulator and a Honeywell thermostatic mixing valve assure a safe and comfortable temperature of hot water for every fixture.
  • Low Profile
  • The Aqua Logic water heater is designed to slide directly underneath a wall-mounted WM97+ hot water boiler. Space heating and domestic hot water production can be condensed into an attractive column with dimensions of 73.5" H x 25.25" W x 19.3125" D.
  • Programmable Schedule
  • Using the WM97+'s control panel, the Aqua Logic may be set to adhere to a schedule. High demand times such as the early morning may be designated as such without sacrificing efficiency in the afternoon, when less hot water is needed.
  • Product Includes
  • (1) Weil-McLain Aqua Logic Companion Water Heater
  • (1) Honeywell AMX302TLF Thermostatic Mixing Valve
  • (1) Taco Three Speed Circulator
  • (1) 3/4" Temperature and Pressure Valve
  • (1) Drain Valve
  • (2) Flexible Stainless Steel Connection Hoses
  • (1) Preconfigured Wiring harness with Plugs
  • (2) Tank Temperature Sensors
  • (3) Adjustable Leveling legs
  • Product Compatible With
  • Weil-McLain WM97+ Hot Water Boilers
Specifications
General Information
Product Line
WM97 Plus
Fuel Type To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
Single
Connection Type
NPT
Mount Type
Floor
UPC
0672619198388
Performance
Minimum Input Capacity
113000 BTU
First Hour Delivery Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
187 Gallons
Continuous Recovery Rate
172 Gallons
Dimensions
Storage Volume
18.2 Gallons
Cold Water Inlet
0.75 Inches
Hot Water Outlet
0.75 Inches
Supply Connection
1 Inch
Return Connection
1 Inch
Product Height
40.1875 Inches
Product Width
19 Inches
Product Depth
19.3125 Inches
Product Weight
60 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Vessel Warranty
10 Years
Product Specs
+
Specifications
General Information
Product Line
WM97 Plus
Fuel Type To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
Single
Connection Type
NPT
Mount Type
Floor
UPC
0672619198388
Performance
Minimum Input Capacity
113000 BTU
First Hour Delivery Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
187 Gallons
Continuous Recovery Rate
172 Gallons
Dimensions
Storage Volume
18.2 Gallons
Cold Water Inlet
0.75 Inches
Hot Water Outlet
0.75 Inches
Supply Connection
1 Inch
Return Connection
1 Inch
Product Height
40.1875 Inches
Product Width
19 Inches
Product Depth
19.3125 Inches
Product Weight
60 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Vessel Warranty
10 Years
