Weil-McLain Aqua Pro 30 - 30 Gal. - Indirect Water Heater



Write a Review
Free Shipping
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Ships in 4-7 Business Days
Shipping Details
  • Lift Gate Service Available - Free Lift Gate Learn More
*We currently CANNOT ship this product to Canada or any destination outside of the United States
$212 / Month
Suggested monthly payments with 6 month financing.
Available Add-Ons
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Weil-McLain Aqua Pro 30 - 30 Gal. - Indirect Water Heater
Weil-McLain Aqua Pro 30 - 30 Gal. - Indirect Water Heater
Model: 633500200
How-To Articles


    Over the last 130 years, Weil-McLain has built a reputation of designing some of the most reliable boilers in the marketplace. If you want to leverage the power and efficiency of your boiler for domestic hot water, then the Aqua Pro 30 is a great choice. The Aqua Pro is a domestic hot water option that fits many applications and is designed for ease of installation in any system. Ideal for all types of water conditions, but in particular harsh enviroments, the Aqua Pro 30 is designed to install easily into any system.
  • Composite Tank Construction
  • The composite tank of the Aqua Pro 30 is lightweight and easily maneuvered. The non-metallic material stands up to corrosion, making it ideal for environments with even the harshest water conditions.
  • No Annual Maintenance
  • With the seamless, no-weld design of the Aqua Pro 30, there is no need for an anode rod, eliminating annual maintenance requirements.
  • Efficiency Boosting Insulation
  • Discouraging heat loss is one of the best ways to improve efficiency. The Aqua Pro 30 has two inches of dense foam insulation that brings heat loss as low as 0.8 degrees per hour.
  • Digital Control
  • The Aqua Pro 30 features a digital thermostat that ensures precise accuracy for optimal performance.
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov


General Information
Indirect Water Heater
Product Line
Aqua Pro
Medium Learn More
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Coils Quantity
Connection Type
First Hour Delivery Learn More
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
199 Gallons
Continuous Recovery Rate
177 Gallons
Storage Volume
30 Gallons
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Supply Connection
3/4 Inch
Return Connection
3/4 Inch
Product Height
40 1/2 Inches
Product Width
22 3/4 Inches
Product Weight
70 Pounds
Shipping Height
44 Inches
Shipping Width
25 Inches
Shipping Length
25 Inches
Shipping Weight
80 Pounds
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Vessel Warranty
10 Years
