Triangle Tube PTE110 - 99K BTU - 95.0% AFUE - Combi Gas Boiler - Direct Vent

Triangle Tube PTE110 - 99K BTU - 95.0% AFUE - Combi Gas Boiler - Direct Vent
Model: PTE110
Product Discontinued
Sorry, this product is no longer available.
Discontinued
Sorry, this product is no longer available
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • 1
    Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    Triangle Tube is best known for two things: feats of hydronic innovation and incredibly efficient products. The Prestige Excellence line adds an internal Indirect Fired tank-in-tank water heater to the Triangle Tube's Prestige Solo hot water boiler. The condensing technology behind Prestige Excellence boilers will capture and reuse gaseous heat that escapes traditional boilers. Stainless steel construction and an internal condensate trap will protect the PTE110 from corrosion. Prestige Excellences also include a modulating burner that scales heat production based on your needs and reduces unnecessary energy consumption. The included tank-in-tank water heater uses boiler water to heat your domestic hot water supply. By including this component inside of the cabinet, your energy will be heating your home and water simultaneously. The TriMax control allows you to have two different temperature zones and six Prestige boilers in your system. It also displays all problems in clear English and suggests common solutions. With the TriMax, controlling and maintaining your boiler is easier than ever. The Prestige Excellence is an overachiever in every regard, and it makes an excellent addition to any system.
  • 60 Second Setup
  • TriMax controls feature six preprogrammed applications that allow you to set the PTE110 up in just one minute. These applications are: finned tube baseboard, cast-iron baseboard, radiators, high mass radiant, and low mass radiant.
  • Fire Tube Heat Exchanger
  • The Prestige Excellence line of combi boilers includes a fire tube heat exchanger. By allowing for high water content, fire tube heat exchangers reduce short cycling and provide incredibly steady temperatures.
  • Outdoor Reset Control
  • All Prestige Solo boilers include an outdoor temperature sensor. When connected to the TriMax control, this sensor allows you to use outdoor reset control to provide the ideal indoor temperature.
  • TriMax Control
  • The TriMax control is one of the most versatile proprietary controls in the business. It includes warm weather shutdown, low water cut off, and allows your system to interface with Modbus communications protocols.
  • Tank-in-Tank Safety
  • High temperatures prevent the growth of bacteria. High quality stainless steel and Triangle Tube's tank-in-tank design allow your domestic hot water to be stored at higher temperatures than traditional water heaters.
  • Product Includes
  • (1) Triangle Tube PTE110 Hot Water Combi Boiler
  • (1) Outdoor Reset Sensor
  • (1) TriMax Control Module
  • (1) Wall Mounting Bracket
  • (1) Circulator
Specifications
General Information
Product Line
Prestige TriMax Excellence
Medium Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type
Condensing
Vent Type Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
DHW Production DHW (Domestic Hot Water) is potable water for uses other than space heat. Some boilers are able to provide DHW "out of the box", while others can do so with the purchase of optional accessories.
Yes
Modulating/Staging Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Modulating
Connection Type
NPT
Mount Type
Wall
Minimum Altitude
0 Feet
Maximum Altitude
2000 Feet
Includes Pump
Yes
Assembly Type
Packaged
Gas Conversion Kit
Not Convertible
Performance
Maximum Input Capacity The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
110000 BTU
Minimum Input Capacity
30000 BTU
DOE Heating Capacity Also referred to as Gross Output, this is the output of a boiler after accounting for combustion efficiency. We recommend sizing hot water boilers based on the DOE Heating Capacity.
99000 BTU
Net I=B=R Capacity I=B=R, also referred to as Net Output or AHRI Capacity, is the rated heat output of a boiler after accounting for combustion efficiency, piping loss, and an extra pickup factor. We recommend sizing steam boilers based on the I=B=R rating.
86000 BTU
AFUE AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
95 %
Ultra Low NOx Emissions NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Flue Connection Size
3 Inches
Gas Connection Size
0.5 Inches
Cold Water Inlet
0.75 Inches
Hot Water Outlet
0.75 Inches
Supply Connection
1 Inch
Return Connection
1 Inch
Product Height
37.2 Inches
Product Width
24.7 Inches
Product Depth
20.8 Inches
Shipping Weight
190 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Heat Exchanger Warranty
10 Years
Certifications
Energy Star Listed
Yes
ETL Listed
Yes
ASME Certified
Yes
AHRI Certified
Yes
ISO Certified
Yes
AHRI Reference Number
2101292
Features
