Takagi T-H3 - 6.3 GPM at 60° F Rise - 0.93 UEF - Propane Tankless Water Heater - Direct Vent
Takagi T-H3 - 6.3 GPM at 60° F Rise - 0.93 UEF - Propane Tankless Water Heater - Direct Vent
+
Share This Product
-
Product Description
-
35Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Fuel
Location
Indoor
# of Showers
UEF
Fuel
Liquid Propane
Location
Indoor
#of Showers
3.0
Uniform Energy Factor
0.93
Energy Star Rated
Yes
Features
Features
- High Efficiency Condensing Technology
- The T-H3-DV-P features the latest in water heating condensing technology. This means that the unit can deliver some of the highest efficiency standards on the market, keeping dollars in your pocket.
- Ultra-Low NOx Emissions
- The T-H3-DV-P is designed to qualify for the most stringent Low NOx standards. This includes SCAQMD standards and other air quality management districts meant to limit pollution in the southwest United States.
- Dual Heat Exchangers
- The primary exchanger is made of commercial-grade HRS35 copper, designed to be more resilient against corrosion. The backup is made of stainless steel, also designed to protect against corrosion.
- Multiple Safety Features
- T-H3 models come with a long list of safety features standard. These include: an air-fuel ratio sensor, exhaust and water temperature safety controls, an overheat cut-off fuse, and an internal freeze protection system.
- Installation and Control Options
- The T-H3 models come with an Easy-Link feature allowing up to four units to be connected without any additional parts or accessories. All T-H3-DV units also come with a built-in temperature control and advanced diagnostics to simplify troubleshooting.
Takagi has been delivering innovative residential and commercial hot water solutions for over 60 years. Their line of tankless water heaters are unmatched in quality and diversity, providing the perfect hot water solution for any situation. The T-H3-DV-P is part of Takagi's high efficiency condensing line of water heaters. Condensing technology paired with an Ultra-Low NOx standard gives the T-H3-DV-P a top of the line .95 Uniform Energy Factor, making this one of the most efficient heaters on the market. With an included control and the ability to link up to 4 units, the T-H3-DV-P is the perfect answer to all your hot water problems.
Specifications
General Information
Type
Tankless Water Heater
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Heat Exchanger Material
Copper/Stainless
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Liquid Propane
Combustion Type
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Condensing
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Venting Category
Venting Category
Venting Category describes what type of flue material can be used in water heater installations. Category III: Stainless Steel, Category IV: ABS, PVC, CPVC, PolyPro, Stainless Steel
IV
Storage Type
Tankless
Mount Type
Wall
Installation Location
Indoor
Maximum Altitude
10100 Feet
Includes Pump
No
UPC
671657141233
Additional Model Numbers
T-H3-DV-P, T-H3-DV-LP
Performance
Maximum Input Capacity
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
199000 BTU
Minimum Input Capacity
19500 BTU
Flow Rate at 40F Temperature Rise
Flow Rate at 40F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
9.5 GPM
Flow Rate at 50F Temperature Rise
Flow Rate at 50F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
7.5 GPM
Flow Rate at 60F Temperature Rise
Flow Rate at 60F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
6.3 GPM
Flow Rate at 70F Temperature Rise
Flow Rate at 70F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
5.4 GPM
Uniform Energy Factor
Uniform Energy Factor
Uniform Energy Factor (UEF) is a measurement of water heater energy efficiency. The higher the energy factor, the more efficient the water heater.
0.93
Minimum Flow Rate
0.5 GPM
Flow Rate at 77F Temperature Rise
4.8 GPM
Ultra Low NOx Emissions
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Primary Vent Pipe Diameter
4 Inches
Gas Connection Size
3/4 Inch
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Product Height
22 1/2 Inches
Product Width
17 3/4 Inches
Product Depth
10 3/4 Inches
Product Weight
59 Pounds
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
AHRI Certified
Yes
NSF Certified
NSF Certified
The National Sanitation Foundation has developed public health standards and certification programs to protect the world's food, water, consumer products and environment.
Yes
AHRI Reference Number
5526768
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
15 Years
Fuel
Location
Indoor
# of Showers
UEF
Fuel
Liquid Propane
Location
Indoor
#of Showers
3.0
Uniform Energy Factor
0.93
Energy Star Rated
Yes
Features
Features
- High Efficiency Condensing Technology
- The T-H3-DV-P features the latest in water heating condensing technology. This means that the unit can deliver some of the highest efficiency standards on the market, keeping dollars in your pocket.
- Ultra-Low NOx Emissions
- The T-H3-DV-P is designed to qualify for the most stringent Low NOx standards. This includes SCAQMD standards and other air quality management districts meant to limit pollution in the southwest United States.
- Dual Heat Exchangers
- The primary exchanger is made of commercial-grade HRS35 copper, designed to be more resilient against corrosion. The backup is made of stainless steel, also designed to protect against corrosion.
- Multiple Safety Features
- T-H3 models come with a long list of safety features standard. These include: an air-fuel ratio sensor, exhaust and water temperature safety controls, an overheat cut-off fuse, and an internal freeze protection system.
- Installation and Control Options
- The T-H3 models come with an Easy-Link feature allowing up to four units to be connected without any additional parts or accessories. All T-H3-DV units also come with a built-in temperature control and advanced diagnostics to simplify troubleshooting.
Takagi has been delivering innovative residential and commercial hot water solutions for over 60 years. Their line of tankless water heaters are unmatched in quality and diversity, providing the perfect hot water solution for any situation. The T-H3-DV-P is part of Takagi's high efficiency condensing line of water heaters. Condensing technology paired with an Ultra-Low NOx standard gives the T-H3-DV-P a top of the line .95 Uniform Energy Factor, making this one of the most efficient heaters on the market. With an included control and the ability to link up to 4 units, the T-H3-DV-P is the perfect answer to all your hot water problems.
Specifications
General Information
Type
Tankless Water Heater
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Heat Exchanger Material
Copper/Stainless
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Liquid Propane
Combustion Type
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Condensing
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Venting Category
Venting Category
Venting Category describes what type of flue material can be used in water heater installations. Category III: Stainless Steel, Category IV: ABS, PVC, CPVC, PolyPro, Stainless Steel
IV
Storage Type
Tankless
Mount Type
Wall
Installation Location
Indoor
Maximum Altitude
10100 Feet
Includes Pump
No
UPC
671657141233
Additional Model Numbers
T-H3-DV-P, T-H3-DV-LP
Performance
Maximum Input Capacity
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
199000 BTU
Minimum Input Capacity
19500 BTU
Flow Rate at 40F Temperature Rise
Flow Rate at 40F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
9.5 GPM
Flow Rate at 50F Temperature Rise
Flow Rate at 50F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
7.5 GPM
Flow Rate at 60F Temperature Rise
Flow Rate at 60F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
6.3 GPM
Flow Rate at 70F Temperature Rise
Flow Rate at 70F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
5.4 GPM
Uniform Energy Factor
Uniform Energy Factor
Uniform Energy Factor (UEF) is a measurement of water heater energy efficiency. The higher the energy factor, the more efficient the water heater.
0.93
Minimum Flow Rate
0.5 GPM
Flow Rate at 77F Temperature Rise
4.8 GPM
Ultra Low NOx Emissions
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Primary Vent Pipe Diameter
4 Inches
Gas Connection Size
3/4 Inch
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Product Height
22 1/2 Inches
Product Width
17 3/4 Inches
Product Depth
10 3/4 Inches
Product Weight
59 Pounds
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
AHRI Certified
Yes
NSF Certified
NSF Certified
The National Sanitation Foundation has developed public health standards and certification programs to protect the world's food, water, consumer products and environment.
Yes
AHRI Reference Number
5526768
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
15 Years
