Taco 0013-F3
Taco 0013-F3
Hover to zoom
1 Of 5
Taco 0013 - 1/6 HP - Circulator Pump - Cast Iron - Rotated Flange
Model: 0013-F3
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews(1)
Write a Review
$338.23
Free Shipping
Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships in 2-3 Business Days
Shipping to60601
Shipping Details
*We currently CANNOT ship this product to Canada or any destination outside of the United States

Share
  • Product Description
  • 1
    Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    Taco is at the forefront of circulator innovation. Their drive to provide the most efficient, reliable pumps in the industry can be seen across their entire catalog. Systems with a high head and high flow requirements can be hard on circulators. The durability, reliability, and power of the 0013-F make it ideal for such situations. Capable of providing efficient circulation for a litany of applications, the 0013-F makes circulation easy for smaller businesses and larger residences. The universal flange-to-flange dimension of the 0013-F makes it quick to install, even if you are replacing a different pump. A design that circumvents the need for traditional maintenance is coupled with durable components to provide you peace of mind. With Taco, your hydronic circulation is in good hands.
  • Maintenance Free
  • Taco's "00" series features a self-lubricating design that improves reliability by eliminating the need for a mechanical seal. In low temperature applications, protection from corrosion is provided by an anti-condensate baffle.
  • Replaceable Cartridge Design
  • All of the circulator's moving parts are contained within a removable cartridge. Servicing a "00" series pump is as easy as replacing this cartridge.
  • High Capacity, High Efficiency
  • In the "00" series, powerful pumps are backed by a direct-drive design. Direct-drive mechanisms are known for their efficiency, longevity, and low noise levels, qualities that translate well to any application.
  • Typical Product Applications
  • Hydronic Heating
  • Chilled Water Cooling
  • High Pressure Drop Boilers
  • Fan Coil Units
  • Heat Exchangers
  • Large Radiant Systems
  • Heat Recovery & Geothermal
  • Product Note
    Cast iron cannot be used in domestic hot water or potable water applications.
Specifications
General Information
Type
Circulator
Product Line
0013 Series
Motor Type
Single Speed
Connection Type
Flanged
Material
Cast Iron
Flange Orientation
Rotated
DHW Compatible Learn More
DHW Compatible
Can be used in Domestic Hot Water applications (baths, sinks, showers).
No
UPC
687752210590
Performance
Maximum Head
33 Feet
Maximum Flow Rate
34 GPM
Maximum Fluid Temperature
230 F
Horsepower
2/12
Maximum Operating Pressure
125 PSI
RPM
3250 RPM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Current Draw
2 Amps
Dimensions
Product Height
6 1/2 Inches
Product Width
6 Inches
Product Depth
7 1/2 Inches
Product Weight
12 Pounds
Shipping Weight
14 Pounds
Certifications
UL Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
3 Years
Features
Features
    Taco is at the forefront of circulator innovation. Their drive to provide the most efficient, reliable pumps in the industry can be seen across their entire catalog. Systems with a high head and high flow requirements can be hard on circulators. The durability, reliability, and power of the 0013-F make it ideal for such situations. Capable of providing efficient circulation for a litany of applications, the 0013-F makes circulation easy for smaller businesses and larger residences. The universal flange-to-flange dimension of the 0013-F makes it quick to install, even if you are replacing a different pump. A design that circumvents the need for traditional maintenance is coupled with durable components to provide you peace of mind. With Taco, your hydronic circulation is in good hands.
  • Maintenance Free
  • Taco's "00" series features a self-lubricating design that improves reliability by eliminating the need for a mechanical seal. In low temperature applications, protection from corrosion is provided by an anti-condensate baffle.
  • Replaceable Cartridge Design
  • All of the circulator's moving parts are contained within a removable cartridge. Servicing a "00" series pump is as easy as replacing this cartridge.
  • High Capacity, High Efficiency
  • In the "00" series, powerful pumps are backed by a direct-drive design. Direct-drive mechanisms are known for their efficiency, longevity, and low noise levels, qualities that translate well to any application.
  • Typical Product Applications
  • Hydronic Heating
  • Chilled Water Cooling
  • High Pressure Drop Boilers
  • Fan Coil Units
  • Heat Exchangers
  • Large Radiant Systems
  • Heat Recovery & Geothermal
  • Product Note
    Cast iron cannot be used in domestic hot water or potable water applications.
Specifications
General Information
Type
Circulator
Product Line
0013 Series
Motor Type
Single Speed
Connection Type
Flanged
Material
Cast Iron
Flange Orientation
Rotated
DHW Compatible Learn More
DHW Compatible
Can be used in Domestic Hot Water applications (baths, sinks, showers).
No
UPC
687752210590
Performance
Maximum Head
33 Feet
Maximum Flow Rate
34 GPM
Maximum Fluid Temperature
230 F
Horsepower
2/12
Maximum Operating Pressure
125 PSI
RPM
3250 RPM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Current Draw
2 Amps
Dimensions
Product Height
6 1/2 Inches
Product Width
6 Inches
Product Depth
7 1/2 Inches
Product Weight
12 Pounds
Shipping Weight
14 Pounds
Certifications
UL Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
3 Years
Product Specs
+
Specifications
General Information
Type
Circulator
Product Line
0013 Series
Motor Type
Single Speed
Connection Type
Flanged
Material
Cast Iron
Flange Orientation
Rotated
DHW Compatible Learn More
DHW Compatible
Can be used in Domestic Hot Water applications (baths, sinks, showers).
No
UPC
687752210590
Performance
Maximum Head
33 Feet
Maximum Flow Rate
34 GPM
Maximum Fluid Temperature
230 F
Horsepower
2/12
Maximum Operating Pressure
125 PSI
RPM
3250 RPM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Current Draw
2 Amps
Dimensions
Product Height
6 1/2 Inches
Product Width
6 Inches
Product Depth
7 1/2 Inches
Product Weight
12 Pounds
Shipping Weight
14 Pounds
Certifications
UL Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
3 Years
