Soler & Palau TR Series - 500 CFM - Energy Recovery Ventilator (ERV) - All Climates - 115V - Side Ports - 16 x 2 Duct

Model:

TRC500-115

Write A Review
$3,667.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
This Item Is Built To Order
synchrony card logo
$65 / Month
With our 86 months 11.99% APR*
86 fixed monthly payments required.
Soler & Palau TR Series - 500 CFM - Energy Recovery Ventilator (ERV) -  All Climates - 115V - Side Ports - 16 x 2 Duct
Soler & Palau TR Series - 500 CFM - Energy Recovery Ventilator (ERV) - All Climates - 115V - Side Ports - 16 x 2 Duct
Model: TRC500-115
$3,667.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Classified as "The Ultimate ERV", this series is designed and certified for use in all climates, from areas prone to hot, humid summers to areas with the most extreme winters. The Models TRC exhaust stale air, bring in fresh air and save energy year-round. S&P's TRCs moderate extremes in both temperature and humidity, creating a comfortable indoor environment. The unique moisture transfer capability of the S&P core also eliminates condensation and frost build up in most applications. No mechanical or electrical defrost systems are needed, which means higher heat recovery efficiencies, easier installation and more reliable operation.
  • Soler & Palau TRC500-115 Features
  • AHRI certified performance data for efficiency and cross leakage
  • UL tested flammability and smoke generation that meets NFPA 90A and 90B test standards for commercial applications
  • Easy installation and service
  • Easiest maintenance of any ERV
  • 2 MERV-8 filters
  • Non-Fused disconnect
  • Transformer/relay package allowing simple on/off control
  • Access doors for easy access to blowers, core and filters
  • Integral mounting flange and hanging bracket system
  • 2 Direct Drive, TEFC, Premium Efficient blower motors
  • Fully insulated case
  • Large cores for high efficiency
  • No condensate pan or drain required
California residents see
Warning: This product can expose you to chemicals including Formaldehyde (gas) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

TRC500-115
specs product image PID-50186
Overview
Product Category
Energy Recovery Ventilators (ERVs)
UPC
812482010565
General Information
Type
ERV
Product Line
TR
Product Category
Energy Recovery Ventilators (ERVs)
Port Location
Side
Performance
Maximum Air Flow
600 CFM
Minimum Air Flow
225 CFM
Sensible Recovery Efficiency
68 %
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Dimensions
Product Height
18 Inches
Product Width
41 Inches
Product Depth
48 Inches
Product Weight
160 Pounds
Shipping Weight
170 Pounds
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Heat Exchanger Warranty
10 Years
