WeatherKing By Rheem TCF - 2 Ton - High Efficiency - Multi-Position N Coil - Cased - 21" Width
Model:
TCF2421HTAMCA
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Bob, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- Aluminum Coil
- The TCF features an evaporator constructed of aluminum fins bonded to internally grooved aluminum tubing. The design maximizes surface area and optimizes heat transfer for efficient comfort.
- Included TXV
- An included thermal expansion valve with a metering device provides accurate refrigerant flow so you can get the most out of your comfort system.
- Drain Connections
- Condensate in a coil must be adequately removed for efficiency and longevity. Two sets of 3/4" NPT condensate drain connections are included on the TCF to simplify removal, while its drain pan is constructed of corrosion free material for durability.
- Factory Tested
- Each TCF coil is tested at the factory to ensure it meets WeatherKing's highest standards and is ready for action, right out of the box.
- Multi-Refrigerant Compatibility
- R-22 refrigerant is no longer in production, but many older systems still use it. The TCF is compatible with both R-22 and its replacement, R-410A.
Reliability, functionality, efficiency - these are values that Rheem holds to the highest standards in the WeatherKing line of HVAC systems. Because coils make such a big difference in the efficiency of heating and cooling systems in your home, WeatherKing puts in the extra effort to make their coils dependable. The TCF coils feature aluminum fins bonded to internally grooved aluminum tubing with copper sweat refrigerant connections. The coil's unique "N" design maximizes performance while its condensate drain pan is made from high grade, heat resistant and corrosion-free thermal set material to ensure durability.
Product Note
A conversion kit is required if converting from R-410A to R-22 refrigerant.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
TCF2421HTAMCA
Overview
Product Category
Evaporator Coil
UPC
662021412486
General Information
Type
Evaporator Coil
Product Line
WeatherKing
Product Sub-line
TCF
Product Category
Evaporator Coil
Refrigerant Type
R-410A
Casing
Cased
Style
N Coil
Configuration
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Multi-Position
Performance
Capacity
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
2.0 Tons
Cooling BTU
24000
Dimensions
Suction Connection Size
3/4 Inch
Liquid Connection Size
3/8 Inch
Cabinet Width
21 Inches
Product Height
20 Inches
Product Width
21 Inches
Product Depth
19 7/8 Inches
Product Weight
60 Pounds
Shipping Weight
70 Pounds
Certifications
UL Listed
Yes
AHRI Certified
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
