Reznor UDAS-100 Gas Fired Unit Heater, Separated Combustion, NG, Aluminized Heat Exchanger - 105,000 BTU

Model:

UDAS-100

Write a Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Reznor UDAS-100 Gas Fired Unit Heater, Separated Combustion, NG, Aluminized Heat Exchanger - 105,000 BTU
Reznor UDAS-100 Gas Fired Unit Heater, Separated Combustion, NG, Aluminized Heat Exchanger - 105,000 BTU
Model: UDAS-100
Product Discontinued
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

    The Reznor UDAS is the solution to a cold garage or warehouse. With its seperate combustion, it is the perfect unit heater for areas that have a lot of combustible materials such as saw dust. With a 50-60 degree temperature rise range, you can maintain the temperature you desire. Reznor is the world's oldest and largest manufacturer of gas unit heaters so you know you're getting a product you can trust.
  • Easy Installation
  • The UDAS can be hung by either 2 or 4 points using threaded rods. The low voltage terminal strip is located on the outside of the unit to be able to connect control wiring easy. There is a gas line nipple on the exterior panel for easy gas connection.
  • Low Profile Design
  • The compact design of the Reznor UDAS allows for more overhead clearance than your conventional unit heaters.
  • High Efficiency
  • The patented Tcore one piece burner assembly provides you the highest efficiency of any other unit heater in its class. The UDAS is power vented to force exhaust gases through the flue, resulting in a more efficient heater.
  • Extreme Durability
  • The corrosion resistant aluminized steel heat exchangers are titanium stabilized and are designed to provide extreme longevity.
  • Low Noise Operation
  • With its vibration/noise isolated fan and venter motors, the UDAS produces minimal sound.
  • Product Note
    A vent kit is required for installation of this product. Please select a vent kit from the "Recommended Accessories" tab before checkout. The image above may not reflect actual product features. The Reznor UDAS-100 comes with six horizontal louvers.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

UDAS-100
specs product image PID-46980
General Information
Product Line
UDAS
Heat Exchanger Material
Aluminized Steel
Fuel Type Learn More
Natural Gas
Vent Type Learn More
Power Vent
Configuration Learn More
Horizontal
Mount Type
Suspended
Performance
Heating Capacity
87000 BTU
Maximum Input Capacity Learn More
105000 BTU
Thermal Efficiency
83 %
Maximum Air Flow
1361 CFM
Minimum Air Flow
1361 CFM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Dimensions
Primary Vent Pipe Diameter
4 Inches
Flue Connection Size
4 Inches
Gas Connection Size
1/2 Inch
Gas Piping Diameter
1/2 Inch
Product Height
23 1/8 Inches
Product Width
26 5/8 Inches
Product Depth
28 5/8 Inches
Product Weight
120 Pounds
Shipping Weight
120 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
ANSI Certified
Yes
Warranty Information
Parts Warranty Learn More
5 Years
Heat Exchanger Warranty
10 Years
