Reznor EGEB-19 Suspended Electric Unit Heater, 240V, 3 Phase - 19.8 kW (67,605 BTU)

Model:

EGEB-19-AK6E

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Reznor EGEB-19 Suspended Electric Unit Heater, 240V, 3 Phase - 19.8 kW (67,605 BTU)
Reznor EGEB-19 Suspended Electric Unit Heater, 240V, 3 Phase - 19.8 kW (67,605 BTU)
Model: EGEB-19-AK6E
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

    The Reznor EGEB-19-AK6E Suspended Electric Unit Heater is a 240 volt, standard-duty suspended electric unit heater. It has an maximum heat capacity of 67605 BTU/hr. The Reznor EGEB-19-AK6E Suspended Electric Unit Heater is designed for commercial hallways, stairwells, factories, warehouses, or shipping room installation. Its exterior is coated in an epoxy/polyester powder paint which is corrosion resistant helping to maintain its appearance for years. EGEB-19-AK6E includes wall and ceiling mounting brackets for horizontal air flow mounting and 4 weld nuts for vertical air flow mounting. The EGEB-19-AK6E Suspended Electric Unit Heater has a draw-through design for more evenly heated air and greater heat transfer. Individually adjustable louvers allow for easier directed air flow.
  • Reznor EGEB-19-AK6E Features
  • Draw-through design to evenly heat air
  • 18 and 20 gauge steel cabinet
  • Individually adjustable louvers to direct airflow
  • Stainless steel heating elements with aluminum fins
  • Epoxy/polyester powder paint
  • Two speed fan switch
  • Integral Thermostat
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

EGEB-19-AK6E
specs product image PID-46105
Overview
Product Category
Unit Heater
General Information
Type
Standard
Product Line
EGEB
Product Category
Unit Heater
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Electric
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Horizontal/Vertical
Mount Type
Suspended
Performance
Heating Capacity
67605 BTU
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
67605 BTU
Heating Capacity (kW)
9.9 kW
Maximum Air Flow
1300 CFM
Minimum Air Flow
1300 CFM
Electrical Data
Voltage
240 Volts
Phase
3
Frequency
60 Hz
Current Draw
23.84 Amps
Dimensions
Product Height
24 1/2 Inches
Product Width
22 Inches
Product Depth
15 1/4 Inches
Product Weight
76 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
