Revolv RG1 - 70k BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed
Model:
RG1D70N4
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
1
$180.00
Only 1 In-Stock
Features
- Sealed Combustion
- Revolv RG1 furnaces vent directly to the outdoors and draw in fresh air for combustion through a separately purchased roof jack.
- Multiple Cooling Choices
- RG1 models can be paired with either air conditioners or heat pumps, up to 4 tons or 3.5 tons, respectfully.
- Compact Design
- All Revolv furnaces are designed specifically for manufactured and modular homes. This allows them to be installed in utility rooms or closets and streamlines installation.
- High Quality, Low Maintenance
- Features such as hot surface ignition, sealed bearings on the motors, reliable controllers, and a clean enamel finish means these units are made to last and provide uninterrupted comfort for years.
Revolv is dedicated to bringing efficient comfort to the manufactured and mobile home market. The RG1D70N4 is a downflow furnace capable of providing 70,000 BTU of heating at an 80% efficiency. Designed for easy installation in a variey of manufactured and modular homes, it enjoys a 0" required clearance to combustibles at the rear and sides and only 6" are required at the top of the unit. If you're struggling to effectively and safely heat your manufactured home, the RG1D70N4 is a solution that you can believe in.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
RG1D70N4
General Information
Type
Gas Furnace
Product Line
RG1
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor Type
PSC Multi-Speed
Configuration
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Downflow
Maximum Altitude
2000 Feet
Gas Conversion Kit
Included
UPC
663132332601
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
80 %
Heating BTU
70000
Heating Capacity
57000 BTU
Maximum Air Flow
1480 CFM
Minimum Air Flow
760 CFM
Ultra Low NOx Emissions
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
No
Electrical Data
Phase
1
Frequency
60 Hz
Recommended Breaker Size
15 Amps
Dimensions
Gas Connection Size
1/2 Inch
Product Height
56 Inches
Product Width
19 3/4 Inches
Product Depth
23 3/4 Inches
Product Weight
168 Pounds
Shipping Weight
168 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
8862056
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Heat Exchanger Warranty
10 Years
