Revolv E7 - 35k BTU - Electric Furnace - Manufactured Home - 100% Efficiency - 10 kW - Multi-Position - Multi-Speed - No Coil Cabinet
Model:
E7EM-010
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
2
$3.14
In-Stock
Model: 90013.011820
$11.03
In-Stock
Features
- Multi-Speed ECM Motor
- The E7EM energy efficient blower motor uses the lowest speed it can to deliver precise temperature control for your home while keeping utility bills to a minimum.
- Multi-Position Installation
- Revolv E7EM models are designed specifically to fit any installation. They can be used in both upflow and downflow systems making them the perfect fit for any home.
- Nichrome Heating Elements
- Revolv electric furnaces feature nichrome heating elements, designed to provide long lasting, efficient heating without breaking the bank.
- Multiple Cooling Choices
- E7EM models can be paired with either air conditioners or heat pumps and can handle up to a maximum of 4 tons of cooling.
- High Quality, Low Maintenance
- Features such as sealed bearings on the motors, reliable controllers, and a built-in circuit breakers means these units are made to last and provide uninterrupted comfort for years.
Revolv is dedicated to bringing efficient comfort to the manufactured and mobile home market. The E7EM-010 is a multi-directional electric furnace capable of providing 35,000 BTU of heating at 100% efficiency. Designed for easy installation in a variety of manufactured and modular homes, it enjoys a 0" required clearance to combustibles at the rear and sides and only 6" are required at the front of the unit. If you're struggling to effectively and safely heat your manufactured home, the E7EM-010 is a solution that you can believe in.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
E7EM-010
Overview
Product Category
Furnace
UPC
663132372577
General Information
Type
Electric Furnace
Product Line
E7EM
Product Category
Furnace
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Electric
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor Type
ECM Multi-Speed
Configuration
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Upflow/Downflow
Performance
Heating BTU
31000
Electric Heat Capacity
9.2 kW
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
66 Hz
Minimum Circuit Ampacity
49.9 Amps
Recommended Breaker Size
50 Amps
Dimensions
Product Height
29 Inches
Product Width
20 Inches
Product Depth
24 1/2 Inches
Shipping Weight
75 Pounds
Reviews
(9)
Revolv E7EM-010 Reviews & Ratings
Customer Rating
4.89
(9 Ratings)
5
(8)
(8)4(1)
(1)3(0)
(0)2(0)
(0)1(0)
(0)
Just the ticket for heating my workshop!
By Kenny C
Oregon
Purchased 01/21/2024 |
Review Posted 04/20/2024
I needed a heater to efficiently warm up my 2-car garage turned workshop. This Revolv E7 turned out to be just the ticket. To make it portable, I tipped the cabinet on its side and attached 3" locking casters. Made a 25' pigtail of 10-guage 3-conductor wire and plugged into a dedicated 240v 60amp circuit. I am using a simple thermostat I've mounted to the case (not ideal, but suits the purpose).
I can roll the unit where I need it -- to warm the entire space, or to concentrate heat in selected areas. Makes the hours at a band saw, drill press, etc, much more bearable! It's relatively quiet and very efficient.
I rigged a dropcloth curtain to isolate what I call the "drying room". I can orient the unit at the curtain to heat only one side or the other. Very handy to help dry glue-ups and finishes MUCH quicker without having to heat the entire space.
When not in use, I unplug and coil the pigtail onto a hose reel I mounted on the side of the unit. I roll it under a small workbench where it's out of the way, but very handy to put into instant use.
This setup is not perfect, mind you, but it is the proverbial bee's knees for my needs! This Revolv E7 unit is very efficient and provides all I need to stay comfortable. I am delighted!
There are only two minor downsides to my overall experience:
First, it took nearly 8 weeks from placing my order to the delivery at my front door. I'd like to see more prompt delivery somehow.
Second, I would caution that the setup I have constructed can add significant overall expense. You must use a dedicated 60amp breaker in your panel, preferably wired with 10-guage wire to the outlet. You will need an appropriate 240volt outlet, and the 25' 3-conductor pigtail needs a plug to match. The cost adds up pretty quickly. If your space is not already wired, adding the circuit can involve an expensive electrician. By all means, verify and comply with all your local building codes.
I can roll the unit where I need it -- to warm the entire space, or to concentrate heat in selected areas. Makes the hours at a band saw, drill press, etc, much more bearable! It's relatively quiet and very efficient.
I rigged a dropcloth curtain to isolate what I call the "drying room". I can orient the unit at the curtain to heat only one side or the other. Very handy to help dry glue-ups and finishes MUCH quicker without having to heat the entire space.
When not in use, I unplug and coil the pigtail onto a hose reel I mounted on the side of the unit. I roll it under a small workbench where it's out of the way, but very handy to put into instant use.
This setup is not perfect, mind you, but it is the proverbial bee's knees for my needs! This Revolv E7 unit is very efficient and provides all I need to stay comfortable. I am delighted!
There are only two minor downsides to my overall experience:
First, it took nearly 8 weeks from placing my order to the delivery at my front door. I'd like to see more prompt delivery somehow.
Second, I would caution that the setup I have constructed can add significant overall expense. You must use a dedicated 60amp breaker in your panel, preferably wired with 10-guage wire to the outlet. You will need an appropriate 240volt outlet, and the 25' 3-conductor pigtail needs a plug to match. The cost adds up pretty quickly. If your space is not already wired, adding the circuit can involve an expensive electrician. By all means, verify and comply with all your local building codes.
Kenny C Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Pros:
Easy To Use, Easy To Store
Cons:
Setup costs can add up quickly
Revolv Furnace
By Courtney J
Pennsylvania
Purchased 07/20/2023 |
Review Posted 08/14/2023
The furnace arrived safely and very quickly!
Courtney J Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Cons:
None
Awesome
By Beverly A
Rocky Mount, Virginia
Purchased 01/14/2022 |
Review Posted 02/11/2022
That furnace is awesome and running like a charm
Beverly A Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, Id Buy It Again, Durable, Exceeded Expectations
So Far, So Good.
By William S
Gig Harbor, Washington
Purchased 07/16/2020 |
Review Posted 09/21/2020
Very good price. Easy install with basic electrical experience. The multi speed fan is very strong and quiet. This thing heats my double wide just right.
William S Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, Id Buy It Again, Quiet
Works Great
By Don W
Elma, Washington
Purchased 04/30/2020 |
Review Posted 06/12/2020
Hooked it up works great.. No problems
Don W Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, Price, Id Buy It Again
it is still sitting on the back dck under cover. wll put in a mo
By Jacqueline D.
Pasco, Washington
Purchased 05/11/2020 |
Review Posted 06/03/2020
The website was the best to make sure I got the right replacement furnace. My current furnace is 1976 Coleman which the one I just bouught is a home Coleman. I recieved 7 days from ordering in Eastern Washington. Thank for the GREAT service.
Jacqueline Davis
Jacqueline Davis
Jacqueline D. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Great Company!
By Brenda C
SAVANNAH, Georgia
Purchased 01/16/2020 |
Review Posted 02/07/2020
I was very surprised how quickly the unit arrived. Product was exactly as described and very easy to install. Detailed instructions were very easy to follow. This unit replaced an old one. The new unit installed in less than an hour! It was easy to wire into the old thermostat. The unit worked properly the first time it was turned on.
Brenda C Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, Exceeded Expectations, Id Buy It Again
Best I could find
By Raymond H.
Greensburg, Indiana
Purchased 11/18/2019 |
Review Posted 12/26/2019
Good product
Raymond H. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
This is an amazing product!
By Alexander Z.
Lakeland, Tennessee
Purchased 10/11/2019 |
Review Posted 11/14/2019
This is an amazing product! It’s so quite when it runs and it heats up the house in mins! I would highly recommend this product!
Alexander Z. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
