Revolv E7ED-023
Revolv E7ED-023
Hover to zoom
1 Of 5

Revolv E7 - 75k BTU - Electric Furnace - Manufactured Home - 100% Efficiency - 23 kW - Downflow - Multi-Speed - Includes Coil Cabinet

Model:

E7ED-023

Write a Review
$869.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 7-14 Business Days
Shipping Details
  • Lift Gate Service Available - Free Lift Gate Learn More
*We currently CANNOT ship this product to Canada or any destination outside of the United States
$145 / Month
Suggested monthly payments with 6 month financing.
Available Add-Ons
FREE
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Revolv E7 - 75k BTU - Electric Furnace - Manufactured Home - 100% Efficiency - 23 kW - Downflow - Multi-Speed - Includes Coil Cabinet
Revolv E7 - 75k BTU - Electric Furnace - Manufactured Home - 100% Efficiency - 23 kW - Downflow - Multi-Speed - Includes Coil Cabinet
Model: E7ED-023
$869.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

    Revolv is dedicated to bringing efficient comfort to the manufactured and mobile home market. The E7ED-023 is a downflow electric furnace capable of providing 75,000 BTU of heating at 100% efficiency. Designed for easy installation in a variety of manufactured and modular homes, it enjoys a 0" required clearance to combustibles at the rear and sides. Service clearance of only 6" are required at the front of the unit, if installed in a closet or 18" in an alcove. This model includes a built-in coil cabinet. If you're struggling to effectively and safely heat your manufactured home, the E7ED-023 is a solution that you can believe in.
  • Multi-Speed ECM Motor
  • The E7ED energy efficient blower motor uses the lowest speed it can to deliver precise temperature control for your home while keeping utility bills to a minimum.
  • Nichrome Heating Elements
  • Revolv electric furnaces feature nichrome heating elements, designed to provide long lasting, efficient heating without breaking the bank.
  • Built in Coil Cabinet
  • The Revolv E7ED models come with a coil cabinet built into the unit. This means they are ready for installation without the need to buy additional parts.
  • Multiple Cooling Choices
  • E7ED models can be paired with either air conditioners or heat pumps and can handle up to a maximum of 4 tons of cooling.
  • High Quality, Low Maintenance
  • Features such as sealed bearings on the motors, reliable controllers, and a built-in circuit breakers means these units are made to last and provide uninterrupted comfort for years.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

E7ED-023
General Information
Type
Electric Furnace
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Electric
Modulating/Staging Learn More
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor
ECM Multi-Speed
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Downflow
UPC
663132372713
Performance
Heating BTU
75000
Electric Heat Capacity
21.6 kW
Electrical Data
Phase
1
Minimum Circuit Ampacity
117 Amps
Recommended Breaker Size
125 Amps
Dimensions
Product Height
60 5/8 Inches
Product Width
20 Inches
Product Depth
24 1/2 Inches
Product Weight
112 Pounds
Shipping Weight
112 Pounds
