Oxbox JMM4 - 3.0 Ton - Wall Mount Air Handler - Upflow - PSC Motor

Model:

JMM4A0B36S31SAA

Write A Review
$813.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
synchrony card logo
$136 / Month
Suggested monthly payments with 6 month financing.
Oxbox JMM4 - 3.0 Ton - Wall Mount Air Handler - Upflow - PSC Motor
Oxbox JMM4 - 3.0 Ton - Wall Mount Air Handler - Upflow - PSC Motor
Model: JMM4A0B36S31SAA
$813.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Bob, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Oxbox wall mount air handler is designed to supplement your air conditioner or heat pump by circulating cooled or heated air throughout your home. The air handler\'s compact size allows it to be wall mounted in a small closet or attic. An all-aluminum coil provides efficient heat transfer while its factory installed refrigerant control device keeps the unit running efficiently over the years.
  • Wall Mounted
  • The Oxbox wall mount air handler's compact size allows for installation in a small closet or open attic.
  • All-aluminum Coil
  • The Oxbox wall mount air handler includes an all-aluminum coil for advanced heat transfer and efficiency.
  • Painted Metal Cabinet
  • The wall mount air handler features a painted metal cabinet for durability and foil face insulation to ensure efficiency.
  • Built-in Filter Rack
  • A built-in filter rack is included with the wall mount air handler for added convenience.
  • Product Note
  • In order to maintain the warranty, product must be installed by a licensed contractor. Proof of installation by a licensed contractor is required.
California residents see
Warning: This product can expose you to chemicals including Lead and lead compounds which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

JMM4A0B36S31SAA
specs product image PID-110396
Overview
Product Category
Air Handler
General Information
Type
Air Handler
Product Line
JMM4
Product Category
Air Handler
Refrigerant Type
R-410A
Blower Motor Speed
Multi-Speed
Motor Type
PSC
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Upflow
Installation Location
Indoor
Performance
Capacity Learn More
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
3.0 Tons
Cooling BTU
36000
Maximum Air Flow
1149 CFM
Minimum Air Flow
726 CFM
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
2.3 Amps
Recommended Breaker Size
15 Amps
Dimensions
Suction Connection Size
3/4 Inch
Liquid Connection Size
3/8 Inch
Product Height
39 1/2 Inches
Product Width
22 Inches
Product Depth
19 Inches
Product Weight
106 Pounds
Shipping Height
42 9/16 Inches
Shipping Width
21 7/24 Inches
Shipping Length
24 1/4 Inches
Shipping Weight
119 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
Warranty Information
Unit Replacement Warranty
1 Year
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
