Features
- Precision Temperature Control Technology
- The MXZ-8C60NA2 outdoor condenser is equipped with inverter technology and an electronic linear expansion valve. These components improve temperature accuracy and system efficiency through precise adjustments of both compressor speed and refrigerant flow.
- Mix and Match
- The MXZ-8C60NA2 is compatible with more than a dozen different indoor units, including ceiling cassette models, concealed duct models, floor standing models, and wall mounted models. This makes it easy to design a system that suits your home.
- Product Compatible With
- Mitsubishi MSZ-FH Wall Mounted Mini Split Indoor Units
- Mitsubishi MSZ-GL Wall Mounted Mini Split Indoor Units
- Mitsubishi MSZ-EF Wall Mounted Mini Split Indoor Units
- Mitsubishi MFZ-KA Floor Standing Mini Split Indoor Units
- Mitsubishi MFZ-KJ Floor Standing Mini Split Indoor Units
- Mitsubishi SLZ-KA Ceiling Recessed Mini Split Indoor Units
- Mitsubishi SEZ-KD Horizontal-Ducted Mini Split Indoor Units
- Branch Box - A Mitsubishi branch box is required to connect this condenser to Mitsubishi mini split indoor units.
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
- Port Adapter - The Mitsubishi ADP5834 port adapter is required to connect the 5/8 inch line set to the 3/4 inch condenser port when installing a multi-zone mini split system.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing.
- Disconnect Box & Electrical Whip Kit - The Disconnect Box & Whip Kit provides a safe and simple way to connect your outdoor condenser to your fuse box.
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
- Outdoor Condenser Plastic Pad (Optional) - This pad provides an even surface, free of debris, on which to place your outdoor condenser.
- Wall Bracket (Optional) - A simple and sturdy way to mount your outdoor condenser off of the ground.
For over 50 years, Mitsubishi has remained at the forefront of the mini split industry thanks to their dedication to providing efficient, user-friendly comfort solutions. The MXZ-8C60NA2 is an outdoor condenser for use in multi-zone mini split applications. It supports up to eight indoor units, allowing you to create a custom zoned heating and cooling system based entirely around the specific needs of your home. With a broad range of compatible indoor units and efficiency-boosting inverter technology, the MXZ-8C60NA2 is a smart addition for nearly any home.
Product Note
This product also requires at least two compatible Mitsubishi mini split indoor units and the following accessories for installation:
Specifications
MXZ-8C60NA2
General Information
Type
Outdoor Condenser
Product Line
M-Series
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Maximum Number of Zones
8
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Installation Location
Outdoor
Branch Box Required
Branch Box Required
By making a single connection to the outdoor condenser, a branch box can supply the right amount of refrigerant to multiple indoor units. Learn More
Yes
Performance
Cooling BTU
60000
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
59 dB
Low Ambient Heating
Yes
Minimum Outdoor Temperature for Heating
Minimum Outdoor Temperature for Heating
This is the lowest rated outdoor temperature for heating operation. Because heat pumps rely on heat available in outdoor air, the amount of heat they are able to supply decreases with outdoor temperatures. Learn More
-4 F
Minimum Outdoor Temperature for Cooling
23 F
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Recommended Breaker Size
50 Amps
Dimensions
Maximum Line Length
492 Feet
Gas Connection Size
3/4 Inch
Liquid Connection Size
3/8 Inch
Product Height
52 11/16 Inches
Product Width
41 17/48 Inches
Product Depth
13 Inches
Product Weight
309 Pounds
Shipping Height
56 1/4 Inches
Shipping Width
42 15/16 Inches
Shipping Depth
17 11/16 Inches
Shipping Weight
333 Pounds
Certifications
ETL Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Compressor Warranty
7 Years
