Hydrolevel Safgard 600 Commercial Hot Water Boiler Low Water Cut-Off, 24 VAC, EL1214-SV 3/4" NPT Probe

Hydrolevel Safgard 600 Commercial Hot Water Boiler Low Water Cut-Off, 24 VAC, EL1214-SV 3/4" NPT Probe
Our Price
Compare Prices
Shipping Info
Model: 600SV
$164.00
Factory-Direct
Ships in 4-7 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.

Factory-Direct
Ships in 4-7 Business Days
Shipping Info
Shipping Info
*We currently CANNOT ship this product to California or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    The Safgard Commercial Boiler Low Water Cut-Offs are used as the primary low water cut-off on residential and commercial water boilers. Hydrolevel controls utilize a non-moving, heavy duty, electronic probe to sense liquid levels. The probe can be installed in an equalizing line or directly into a boiler or water tank in accordance with manufacturers' instructions and local and State codes. When water is in contact with the probe, it completes a circuit between the stainless steel probe tip and the tank or boiler surface in which the probe is installed. When the water level drops below the probe, the circuit opens. Hydrolevel low water cut-offs for hydronic heating systems use the water signal to allow the burner to operate. If the water level drops below the probe, the circuit opens and the cut-off shuts down the burner. Automatically restarts burner on return of normal water level.
  • Heavy-duty electro-mechanical design
  • for long life.
  • Automatically shuts off burner in a low water condition
  • to prevent boiler damage.
  • Low maintenance
  • No moving parts to wear stick or hand up, as in float devices.
  • Rugged construction
  • Designed for the heating professional.
  • More Probe Plate Space
  • Large probe tip puts more conductive surface area in the water, leading to more dependable operation and less chance of nuisance boiler shutdowns.
  • Automatic Reset
  • Shuts down the burner when water drops below the probe. Automatically recompletes the burner circuit upon return of a safe water level.
  • Test Button
  • Tests control operation without lowering the water level. Depressing the test button shuts down the burner after two second delay and lights low water indicating LED. Depressing the test button a full 30 seconds will send control into manual reset.
Specifications
General Information
Connection Type
NPT
Performance
Maximum Operating Pressure
160 PSI
Electrical Data
Power Consumption
2 Watts
Voltage
24 Volts
Frequency
60 Hz
Dimensions
Connection Size
0.75 Inches
Product Height
5.5625 Inches
Product Width
5.5 Inches
Product Depth
6.25 Inches
Product Weight
15 Pounds
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
