Honeywell Thermostatic Mixing Valve, 4.3 Cv, 70F to 145F Operating Temperature Range, 1" NPT Connection

Honeywell Thermostatic Mixing Valve, 4.3 Cv, 70F to 145F Operating Temperature Range, 1" NPT Connection
Model: AM102-1
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Discontinued
Sorry, this product is no longer available
Shipping Info
Shipping Info
*We currently CANNOT ship this product to California or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • How-To Articles
  • Manuals
Product Description
+
Features
Features

    Honeywell Thermostatic Mixing Valve, 4.3 Cv, 70F to 145F Operating Temperature Range, 1" NPT Connection

    The Honeywell AM102-1 Thermostatic Mixing Valve accurately adjusts, maintains and limits the hot water temperature to as desired setting selected by the user. In domestic water applications it offers scalding protection and bacteria growth control. With the installation of a Honeywell AM102-1 Thermostatic Mixing Valve and raising water heater storage temperature setting and limiting mixed outlet water temperature to safe temperature, more usable hot water is available. In heating applications it provides comfort and protects the equipment. The Honeywell AM102-1 Thermostatic Mixing Valve has a 1 inch NPT connection, with a Cv of 4.3.

    Honeywell AM102-1 Thermostatic Mixing Valve Features:
    • Dual purpose mixing or diverting valves
    • Constant water temperature under changing operating conditions
    • Reliable performance at minimum flow of .5 gpm
    • Proportional valve (simultaneous control of hot and cold water)
    • Temperature limit at any point
    • Flow reduction in seconds if cold water supply is interrupted
    • Nickel-plated brass construction, EPDM O-Rings
    • High performance thermoplastic proportioning shuttle
    • Straight through design (hot and cold at the same level)
    • Max pressure 150 PSI
    • Max temperature 212F
    • Designed for easy maintenance and element replacement Teflon coating of internal valve components to prevent mineral build-up and extend life
    • Tamper resistant design
    • Valve trapping not required
    • ASSE, CSA and IAPMO listed
    Honeywell AM102-1 Thermostatic Mixing Valve Warranty:
    • Parts: 1 Year
Specifications
General Information
Product Line
AM
Valve Type
Mixing
Connection Type
NPT
UPC
085267825306
Performance
CV Value
4.3
Minimum Operating Temperature
70 F
Maximum Operating Temperature
145 F
Dimensions
Connection Size
1 Inch
Product Weight
1.85 Pounds
Certifications
CSA Listed
Yes
ASSE Certification
Yes
IAPMO Certification
Yes
Warranty Information
Parts Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
