Grundfos TP50-160/2 Direct Coupled In-Line Circulator, 1-1/2 HP, Bronze, 115/208-230V, GF 50 Flange Mount

Grundfos TP50-160/2 Direct Coupled In-Line Circulator, 1-1/2 HP, Bronze, 115/208-230V, GF 50 Flange Mount
Model: 96411816
$3,379.20
Ships in 7-14 Business Days
Free Shipping
Free Lift Gate Service -
Add-Ons

Ships in 7-14 Business Days
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    The Grundfos TP50-160/2 is a direct coupled, single-stage, in-line centrifugal pump with a mechanical shaft seal and the world-renowned IE3 as its standard motor. Grundfos' Blueflux motors are among the most efficient motors available, and are engineered for maximum efficiency at both full and part-capacity. Since it maintains a very high level of efficiency over a broad range of operations, it is ideal for an array of applications. The TP 50-160/2 is a top-pull-out design, meaning the pump head (which includes the motor, motor stool and impeller) can be detached without interfering with the pump housing's pipework. This simplifies the routine service work needed to maintain the performance of these pumps, enabling a single person to service even the largest pumps. The Grundfos TP series pumps are specifically designed for the circulation of liquids in heating and air-conditioning systems. Typical applications for this bronze pump include: district heating/cooling, industrial cooling/processes, boiler/hydronic heating, domestic hot water, chilled water, air conditioning systems, cooling towers, radiant floor heating, solar and snow melt systems.
  • Advanced fan design
  • Results in dramatically reduced noise levels
  • All-in-one-solution
  • The coupling and shaft are friction-welded together in order to create a completely stable mechanical unit, drastically reducing the vibration levels and prolongs the lifetime of the shaft seals and bearings
  • Mechanically and hydraulically balanced impeller
  • Further minimizes vibration levels and axial forces while maximizing motor bearing and shaft seal lifetime
  • Anti-corrosion surface
  • Cataphoresis surface treatment consisting of Powercon cathodic electrocoating and zinc phosphate coating results in maximal protection against corrosion and a longer lasting inside surface that keeps efficiency high
  • Renewable neck rings
  • Makes it easy to upgrade your pump when necessary
  • Unique design of shaft seal chamber
  • Eliminates the need for external piping and ensures optimal water circulation, prolonging the lifetime of the shaft seal
  • Grundfos Blueflux IE3
  • Only motors with the official IE3 logo are certified maximum efficiency motors
  • Compact perfection
  • A large shaft diameter and a short distance from the impeller to the motor maximizes stability and results in lower maintenance costs
Specifications
General Information
Product Line
TP50-160/2
Speed Settings
Variable Speed
Connection Type
Flange
Mount Type
In-Line
Material
Bronze
Drive Type
Close-Coupled
Performance
Maximum Head
52.5 Feet
Maximum Flow Rate
92.5 GPM
Maximum Operating Pressure
145 PSI
Minimum Fluid Temperature
5 F
Maximum Fluid Temperature
284 F
Electrical Data
Voltage
115/208-230 Volts
Phase
1
Frequency
60 Hz
Dimensions
Connection Size
2 Inches
Product Height
14 Inches
Product Width
20.375 Inches
Product Depth
8 Inches
Product Weight
95 Pounds
Warranty Information
Warranty A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
