Gree Terra 12k BTU Wall Mounted Unit - For Multi or Single-Zone

Model:

TERRA12HP230V1AH

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Gree Terra 12k BTU Wall Mounted Unit - For Multi or Single-Zone
Gree Terra 12k BTU Wall Mounted Unit - For Multi or Single-Zone
Model: TERRA12HP230V1AH
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    This product requires a compatible outdoor condenser for functionality.

    For more than 20 years, Gree has been providing energy efficient, dependable heating and air conditioning solutions for residential and commercial use. As the producer of one third of the world's air conditioners, Gree has established itself as a global leader and the Terra TERRA12HP230V1AH mini split indoor unit is their perfect solution for commercial applications where 'always on' reliability is critical. The TERRA12HP230V1AH comes from Gree's Terra line, their highest efficiency indoor units, making this unit ideal if you are looking to provide heating and cooling for a single area or supplement existing heating and air conditioning equipment. The wall mounted indoor unit provides an attractive, compact, quiet comfort solution precisely controlled with the included wireless remote.

    Product Features

    Dehumidify and Cool
    Gree's Terra unit has both a Dry Mode and an X-Fan Mode that demonstrates the TERRA12HP230V1AH's versatility. These provide optimal flexibility and allow for your unit to adapt to changes in humidity, removing excess moisture from your indoor coil.

    Airflow Control
    The airflow direction for this unit may be set to swing between its nine vertical positions and seven different horizontal angles. The unit is easily adjusted using the built-in Swing Louver Display. This disperses the hot or cold air evenly across your zone, resulting in consistent and thorough heating and cooling. Swing mode can be used in a variety of modes including Continuous Sweep.

    I-Feel Function
    Gree's wall-mounted indoor units like the TERRA12HP230V1AH feature an 'I Feel' button that activates a temperature sensing program designed to keep you comfortable wherever you are. Once activated, the remote controller acts as a temperature sensor, sending commands to the unit to keep the room consistently comfortable.

    Quiet Operating Mode
    The TERRA12HP230V1AH operates quietly and is barely noticeable. This operating design automatically adjusts airflow slightly to reduce fan noise in the unit, providing you with perfectly quiet comfort.

    Sleep Mode
    The TERRA12HP230V1AH unit features three different Sleep Modes that incrementally increase or decrease the unit's desired output to decrease energy use and increase savings. When heating and cooling, these modes allow your unit to automatically adjust the set point a few degrees colder and hotter, respectively, during a set sleep schedule before kicking on to allow for decreased waste without any effect upon your sleep cycle. The unit comes preprogrammed with gradual and adaptive cycles, and also offers the ability for a customized cycle that is entirely user-programmed.

    Two-Stage Turbo Fan
    In some cases, you may need to reach the desired temperature in a shorter amount of time. The TERRA12HP230V1AH has a Turbo Mode that allows for an ultra high speed fan to kick in. This will boost the unit's performance in both heating and cooling modes until the feature is deactivated.

    Product Compatibility
    • Gree MULTI18HP230V1BO Mini Split Outdoor Condenser
    • Gree MULTI24HP230V1BO Mini Split Outdoor Condenser
    • Gree MULTI30HP230V1BO Mini Split Outdoor Condenser
    • Gree MULTI36HP230V1BO Mini Split Outdoor Condenser
    • Gree MULTI42HP230V1BO Mini Split outdoor Condenser
    • Gree MULTI48HP230V1AO Mini Split outdoor Condenser
    • Gree MULTI56HP230V1AO Mini Split outdoor Outdoor Condenser
    Product Note

    This product requires the following accessories for installation:

    • Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
    • Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your unit. It connects your indoor units to drain locations of your choosing.
    • Disconnect Box & Electrical Whip Kit - The Disconnect Box & Whip Kit provides a safe and simple way to connect your outdoor condenser to your fuse box.
    • Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
    • Outdoor Condenser Plastic Pad (Optional) - This pad provides an even surface, free of debris, on which to place your outdoor condenser.
    • Wall Bracket (Optional) - A simple and sturdy way to mount your outdoor condenser off of the ground.
    • Adding these accessories along with an outdoor condenser to your order will provide a complete, ready-to-install mini split unit.

California residents see
Warning: This product can expose you to chemicals including Formaldehyde (gas) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

TERRA12HP230V1AH
specs product image PID-50543
General Information
Type
Wall Mounted
Product Line
Terra
Operating Mode Learn More
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s) Learn More
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
12
Installation Location
Indoor
UPC
852036004732
Performance
Cooling BTU
12000
Cooling Capacity
12000 BTU
Maximum Air Flow
453 CFM
Minimum Air Flow
112 CFM
Minimum Sound Level
34 dB
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
44 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
1/2 Inch
Liquid Connection Size
1/4 Inch
Product Height
11 1/2 Inches
Product Width
34 5/48 Inches
Product Depth
8 5/24 Inches
Product Weight
24 Pounds
Shipping Width
37 5/24 Inches
Shipping Height
14 43/48 Inches
Shipping Depth
11 17/24 Inches
Shipping Weight
31 Pounds
Certifications
ETL Listed
Yes
Energy Star Listed
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
