Goodman AWUF - 2 Ton - Air Handler - Wall-Mount - 208-240/1/60 - PSC Motor - 8 kW
Model:
AWUF240816
+
Share This Product
Features
- Galvanized-Steel Cabinet
- Galvanized-steel cabinets are corrosion resistant, requiring less maintenance to remain at peak efficiency.
- All-Aluminum Evaporator Coil
- The AWUF model comes with a durable all-aluminum evaporator coil that optimizes heat transfer.
- Easy Installation
- The AWUF air handler can be installed vertically on the wall with the provided wall hanging bracket. With the 2.0 ton units, you have the ability to choose between a front or bottom return, giving you installation flexibility.
- Electric Heat
- The AWUF air handlers come with a rust-resistant nickel chromium heating element that are sequence-controlled.
- Built-In Filter Rack
- Save money when purchasing the AWUF air handlers by not having to purchase a filter rack and filter in addition to your air handler. The AWUF comes with a built-in filter rack and the filter is included.
- Extended Warranty
- Goodman offers a 10-year limited parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See warranty sheet under the "Manuals" tab for more information.
Goodman air handlers are an integral part of finishing a total home environment control system. The AWUF plays a key role in reducing indoor humidity to create much more comfortable environment. In addition, the AWUF180316 works with the multi-speed PSC motor to efficiently move cooled or warmed air throughout your home at exactly the speed you need.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
AWUF240816
Overview
Product Category
Air Handler
UPC
663051557826
General Information
Type
Air Handler
Product Line
AWUF
Product Category
Air Handler
Refrigerant Type
R-22/R-410A
Blower Motor Type
Multi-Speed
Motor Type
PSC
Mount Type
Wall Mounted
Installation Location
Indoor
Electric Heat
Yes
Installation Available
Yes
TXV Installed
No
Performance
Capacity
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
2.0 Tons
Cooling BTU
24000
Electric Heat Capacity
8.0 kW
Maximum Air Flow
900 CFM
Minimum Air Flow
865 CFM
Electrical Data
Phase
1
Minimum Circuit Ampacity
35 Amps
Recommended Breaker Size
40 Amps
Dimensions
Suction Connection Size
5/8 Inch
Liquid Connection Size
3/8 Inch
Drain Outlet Diameter
3/4 Inch
Product Height
36 Inches
Product Width
20 3/16 Inches
Product Depth
16 1/8 Inches
Product Weight
84 Pounds
Shipping Weight
94 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Warranty
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Years
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Limited Years
Reviews
(4)
Goodman AWUF240816 Reviews & Ratings
Product Q&A
(2)
Product Questions
Answered by Bob, the eComfort Product Expert
What are the correct air filter measurements for this unit?
Gfondeur
from Alabama
August 07, 2016
With this particular Air Handler, must you unscrew and remove a Front Access Panel in order to replace the air filter, or does it provide easy access to the air filter that sits atop the front diagonal rack? If you must unscrew and remove a Front Access Panel, does this Access Panel really serve any purpose?
Eric
from Tennessee
