Model: ALFH1912201E
$62.00
Factory-Direct
Features
- All-Aluminum Coil
- Goodman's evaporator coils use a reliable all-aluminum design featuring fins and grooved tubes. This design maximizes surface area and optimizes heat transfer for efficient comfort.
- Energy-Efficient Circulation
- PSC blower motors are energy hogs. The ECM motor in the ASPT37C14 provides more efficient, more intelligent airflow for your home.
- Dehumidification
- Goodman's air handlers make it easy to stay cool. The ASPT is designed to remove moisture from the air, letting you feel cool at higher temperatures.
- SmartFrame™
- This air handler features Goodman's SmartFrame™ sub-structure for enhanced accessibility. It provides tool-less access to the filter rack and includes a coil mounting track that improves installation speed for all four compatible orientations.
- Secure Cabinet
- This air handler enjoys reduced noise levels, less than 2% air leakage, and enhanced durability as a result of its insulated, embossed cabinet design.
- Condensate Management
- The ASPT's design includes molded diverters, foil-faced insulation, and screw-less construction that help prevent the formation of condensation and keep your system running smoothly.
- Extended Warranty
- Goodman offers a 10-year limited parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See warranty sheet under the "Manuals" tab for more information.
- Internal Thermostatic Expansion Valve
- The ASPT Series Air Handler has a factory-installed internal thermostatic expansion valve. This streamlines installation and maintains ideal refrigerant flow for your system.
The best air conditioner or heat pump in the world is all for naught if your home lacks proper airflow. That's where the Goodman ASPT air handler comes in. The ASPT is all about effective air distribution. It includes an all-aluminum evaporator coil and internal thermostatic expansion valve. These advanced components excel at ensuring that your home stays comfortable and your central system runs efficiently. The ECM fan motor is a huge step up from older models as it requires less electricity to operate and provides more consistent air circulation. The ASPT37C14 was designed and built with an emphasis on keeping the installation process short and the equipment's lifespan long to maximize the value for homeowners. If airflow issues are holding your central system back, invest in an ASPT air handler from Goodman.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
ASPT37C14
Overview
Product Category
Air Handler
UPC
663051559608
General Information
Type
Air Handler
Product Line
ASPT
Product Category
Air Handler
Refrigerant Type
R-410A
Blower Motor Type
Multi-Speed
Motor Type
EEM
Mount Type
Multi-Position
Installation Location
Indoor
Electric Heat
Available
Installation Available
Yes
TXV Installed
Yes
Performance
Capacity
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
3.0 Tons
Cooling BTU
36000
Maximum Air Flow
1565 CFM
Minimum Air Flow
980 CFM
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
6 Amps
Recommended Breaker Size
15 Amps
Dimensions
Suction Connection Size
7/8 Inch
Liquid Connection Size
3/8 Inch
Cabinet Width
21 Inches
Product Height
53 7/16 Inches
Product Width
21 Inches
Product Depth
21 Inches
Product Weight
109 Pounds
Shipping Weight
144 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
Warranty Information
Warranty
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Limited Years
Reviews
(5)
Goodman ASPT37C14 Reviews & Ratings
Customer Photos and Videos
Goodman Quality Easy Install Great Performance
By Pioneer AC.
Florida
Review Posted 08/11/2022
Found the unit to be very quiet. Cools excellently combined with 16 seer Goodman condenser. Very pleased. My electric kw usage was down 18 percent.
Pioneer AC. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, Id Buy It Again, Easy To Store
Cons:
None
Very Good System
By Will C
San Antonio, Texas
Purchased 05/10/2021 |
Review Posted 08/13/2021
Some people talk down Goodman systems but they run well and long. This 16 SEER unit is strong, quiet, and running cheap. Its no louder than my neighbors Lennox. I'm considering buying another to replace my second system. Also, the installation through eComfort/Goodman as quality, fast, efficient and no nonsense or up-sales. I would do it exactly the same again.
Will C Does Not Recommend This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, Exceeded Expectations, Id Buy It Again
Love Goodman and eComfort
By Paul S
NORTH ANDOVER, Massachusetts
Purchased 08/21/2018 |
Review Posted 09/21/2018
I was skeptical about Goodman. I’ve always had Carrier but I have to say this is equal quality and performance at a fraction of the cost. eComfort has also been a great company to work with. You can’t go wrong with Goodman. I would definitely recommend
Paul S Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Easy to configure unit.
By William G.
Boca Raton, Florida
Purchased 07/07/2018 |
Review Posted 08/01/2018
This unit works in vertical or horizontal positions. I removed the horizontal drain pan, as directed by the manual, to optimize vertical air flow. It states it is not required but I want better air flow. The A coil in my 5 ton unit is massive but slides out easily. This is a well constructed unit.
William G. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Terrific product
By James G.
Flower Mound, Texas
Purchased 01/08/2018 |
Review Posted 02/13/2018
Very happy with the 3 ton air handler. It is very compact, quiet and efficient. Already seen a reduction in my heat bill.
James G. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Price, High Quality, I'd Buy It Again
How-To Articles
How Central Air Conditioning Systems Work
Can you imagine life without air conditioning? Oppressive heat waves that can m...
How to Pick the Perfect Evaporator Coil & Air Handler
Evaporator coils and the refrigerant that flows through them are the veins and ...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Goodman ASPT - 3 Ton - Air Handler - Multi-Position - ECM Motor
