Features
- GE Endure Multi Series Concealed Duct Unit Features
- Industry Slimmest Design
- Motorized Grille/Louver (Sold Separately)
- Quiet Operation - Down to 21 dB(A)
- Built-In Condensate Pump
- Built-In WiFi
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing.
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
The Endure Multi Series from GE was designed with innovative technology to achieve complete home comfort, even in frigid climates. The concealed duct unit pairs with the Endure outdoor condenser to provide cooling and heating while remaining quiet, out of sight and efficient. Convenient air flow and scheduling options make this concealed duct unit a perfect addition to your home.
Product Note
The QACT17A Wired Controller is required. Please see the Accessories tab to purchase. This product requires a compatible GE mini split outdoor condenser and the following accessories for indoor unit installation:
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
AD12SL2VHB
Overview
Product Category
Mini Split System Components
General Information
Type
Concealed Duct
Product Line
Endure Series
Product Category
Mini Split System Components
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Indoor Unit Size(s)
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
12
Installation Location
Indoor
Performance
Cooling BTU
12000
Cooling Capacity
12000 BTU
Maximum Air Flow
400 CFM
Minimum Air Flow
218 CFM
Minimum Sound Level
23 dB
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
38 dB
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
1/4 Inch
Liquid Connection Size
3/8 Inch
Product Height
7 1/2 Inches
Product Width
33 1/2 Inches
Product Depth
16 1/2 Inches
Product Weight
36.8 Pounds
Shipping Weight
47.2 Pounds
Certifications
ETL Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Reviews
(1)
GE Mini Splits AD12SL2VHB Reviews & Ratings
How-To Articles
eComfort Boosts Comfort and Energy Savings at Historic Home
Owning a historic home can be very rewarding. But those rewards come with respo...
How to Pick the Perfect Mini Split Ceiling Cassette Unit
Many of us like it when our heating and cooling equipment is out of sight and o...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
GE - 12k BTU - Endure Series Concealed Duct Unit - For Multi-Zone
