Fantech SER - 208 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 8" Duct - Exhaust

Model:

SER3204D

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Fantech SER - 208 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 8
Fantech SER - 208 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 8" Duct - Exhaust
Model: SER3204D
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech SER 3204D Energy Recovery Ventilator (ERV) is a 267 CFM energy recovery ventilator with side ports and exhaust defrost capabilities. The SER 3204D is a 120 volt unit designed with 4 ports with 8" ducts. ERVs make your heating and cooling systems more efficient by transferring heat and humidity between fresh and stale air during ventilation. Its compact size and wall bracket make this ERV easy to mount. The SER 3204D Energy Recovery Ventilator (ERV) features an enthalpy core, washable electrostatic filters, and electronic control board.
  • Heat Recovery Core
  • An aluminum heat recovery core provides improved heat transfer capacity while taking up less space than traditional cores.
  • Winter Guard
  • A built-in exhaust defrost system allows for consistent, reliable operation during the winter months.
  • Electronic Control Board
  • Microprocessor technology efficiently controls operation of the unit making it easy to connect HVAC equipment and wall controls.
  • Washable Electrostatic Filters
  • Electrostatic filters capture airborne particles traveling through the ventilator. Easily washable, these filters can be repeatedly reused before replacement.
  • Product Includes
  • (1) SER 3204D Energy Recovery Ventilator (ERV)
  • (1) Mounting Chains

Specifications

SER3204D
specs product image PID-31169
General Information
Type
ERV
Product Line
SER
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Exhaust
Ports Quantity
4
Port Location
Side
UPC
650737015343
Performance
Maximum Air Flow
239 CFM
Apparent Sensible Effectiveness
73 %
Minimum Air Flow
94 CFM
Total Recovery Efficiency
54 %
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
8 Inches
Product Height
20 1/2 Inches
Product Width
27 7/8 Inches
Product Depth
25 1/4 Inches
Product Weight
80 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
