Fantech ATMO - 201 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 6" Duct

Model:

ATMO 200E

Write A Review
$1,080.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Only 2 In-Stock
Ships Wednesday, Mar 20th
Shipping to60601
synchrony card logo
$180 / Month
Suggested monthly payments with 6 month financing.
Fantech ATMO - 201 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 6
Fantech ATMO - 201 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 6" Duct
Model: ATMO 200E
$1,080.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech ATMO 200E Energy Recovery Ventilator (ERV) is a 201 CFM energy recovery ventilator with side ports and polypropylene heat recovery core. The ATMO 200E is a 120-volt unit designed with 4 ports with 6" ducts. ERVs make your heating and cooling systems more efficient by transferring heat and humidity between fresh and stale air during ventilation. Its compact size and optional wall bracket make this ERV easy to mount. The ATMO 200E Energy Recovery Ventilator (ERV) features a crossflow core and washable electrostatic filters.
  • Exceptional Efficiency
  • The Fantech ATMO is capable of extracting up to 75% of the heat in the extract air is recovered by the heat exchanger and used to temper the fresh air coming from outside.
  • Healthier Home
  • Without proper ventilation, you are subject to indoor air pollutants like chemical products, pet dander or building materials. With an HRV, your home will be ventilated up to 20 times per day, making for a healthier home.
  • Defrost Cycle
  • The Fantech ATMO is equipped with an automatic defrost mechanism that is activated when outdoor air temperature drops to 14F (-10C) or lower.
  • Integrated Merv-3 Filter
  • The Fantech ATMO uses MERV3 a filter for unobstructed airflow and reducing textile fibers, pollen and dust mites.
  • Crossflow Core
  • The Fantech ATMO features provides an efficient crossflow heat exchanger with SRE up to 75% of energy transfer.
  • Insulated One-Piece Foam Cabinet
  • The Fantech ATMO is UL rated with improved aerodynamics, insulation and sound proofing.
  • External Electrical Box
  • The Fantech ATMO has external access to the electrical box with easy connectors.

Specifications

ATMO 200E
specs product image PID-123287
Overview
Product Category
Energy Recovery Ventilators (ERVs)
UPC
650737638917
General Information
Type
ERV
Product Line
ATMO
Product Category
Energy Recovery Ventilators (ERVs)
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Fan Shutdown
Ports Quantity
4
Port Location
Side
Performance
Maximum Air Flow
201 CFM
Apparent Sensible Effectiveness
84 %
Minimum Air Flow
97 CFM
Total Recovery Efficiency
65 %
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
6 Inches
Product Height
18 Inches
Product Width
32 Inches
Product Depth
32 Inches
Product Weight
57 Pounds
Shipping Width
32 Inches
Shipping Height
18 Inches
Shipping Length
32 Inches
Shipping Weight
62 Pounds
Certifications
CSA Listed
Yes
Energy Star Listed
Yes
AHRI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
