Directions - Simply peel the release liner from the mastic before placing the Heat Pump/Condenser Riser and equipment.
Maxium Point Load - A HPR-3-2P or HPR-6-2P Heat Pump/Condenser Riser can handle a point load, applied to one square inch area in center of footpad recess on top of single HPR, of less than 560 pounds with no failure.
Maximum Uniform Load - A HPR-3-2P or HPR-6-2P Heat Pump/Condenser Riser can handle a uniform load of 2000 pounds with no failure.
Advantages - Two-piece, heavy duty plastic unit is manufactured in three heights - 3", 6" and 12" with an optional 4" extension. One-piece 6S model employs structural computergenerated design for strength.
Composition - High-pressure injection molded polypropylene â medium gray color. Butyl mastic on the top and bottom guarantees no slipping.
Purpose - Heat Pump/Condenser Risers provide a sturdy and stable solution for adding elevation to a condenser, heat pump, air handler, or other equipment by allowing airflow which prevents corrosion caused by direct ground contact.
Application - Heat Pumps and Condenser units
Our SKU number(s): Diversitech HPR-6
The manufacturer model number(s): Diversitech HPR-6
