Features
- GeniSys™ Burner Control
- With programmable delays for valve on and motor off, the GeniSys™ burner control is designed for trouble-free operation. Two communication ports on the Patriot 80 furnace allow for alarm contacts and wireless communication.
- Quiet Operation
- Patriot 80 furnaces feature foil-faced, high density fiberglass insulation for minimal noise and heat loss. A dense, ceramic fiber combustion chamber also aids in quiet and efficient operation.
- Built to Last
- A heavy-duty, 14-gauge heat exchanger and a corrosion-resistant steel cabinet allows for reliable operation over the years. The Patriot 80 furnaces even feature easy-access stainless steel clean-out ports for simple heat exchanger servicing.
- Beckett AFG Burner
- Patriot 80 furnaces include a Beckett AFG burner with a flame retention head, PSC burner motor, and solid-state ignition for reliable igniting.
- Versatile
- Available in a variety of configurations, the Patriot 80 furnace can fit in almost any location. Multiple firing rates and a simple nozzle change allows the furnace to accommodate a range of heating capacity requirements.
When it comes to adding reliable warm air comfort to your home, Comfort-Aire has got you covered with their Patriot 80 line of oil furnaces. Featuring programmable controls and reliable components, these oil furnaces are built for trouble-free operation and maintenance for years to come. Not only that, Patriot 80 furnaces include state-of-the-art Beckett AFG burners and ceramic fiber combustion chambers for quiet and efficient heating comfort. Available in upflow, downflow, and horizontal configurations with multiple capacity options, the Patriot 80 can be installed in almost any heating application.
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov
Specifications
OUFB95-D4
Overview
Product Category
Furnace
UPC
847283022073
General Information
Type
Oil Furnace
Product Line
Patriot 80
Product Sub-line
Highboy
Product Category
Furnace
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Oil
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Chimney Vent
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor Type
PSC Multi-Speed
Configuration
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Upflow
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
83 %
Heating BTU
95000
High Fire Input
113500 BTU
High Fire Output
95000 BTU
Low Fire Input
101000 BTU
Low Fire Output
84000 BTU
Maximum Air Flow
1940 CFM
Electrical Data
Phase
1
Frequency
60 Hz
Recommended Breaker Size
15 Amps
Dimensions
Flue Connection Size
6 Inches
Product Height
54 Inches
Product Width
19 1/2 Inches
Product Depth
30 5/8 Inches
Product Weight
250 Pounds
Shipping Weight
250 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
5009583
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
20 Years
Reviews
(1)
Comfort-Aire OUFB95-D4 Reviews & Ratings
Product Q&A
Be the First to Ask A Question
Answered by Ken, the eComfort Product Expert
How-To Articles
Modulating, Single Stage & Two Stage Furnaces
Think back to a time when you were playing a sport. If you’re like me, yo...
An Overview of Furnace Features
Most American homes use a central forced-air system to heat and cool their home...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Comfort-Aire Patriot 80 Highboy - 95k BTU - Oil Furnace - 83% AFUE
