Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread, 1-1/4" Sweat Connections

Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread, 1-1/4" Sweat Connections
Our Price
Compare Prices
Shipping Info
Model: 551035A
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews (0)
Write A Review
$143.65
In-Stock
Ships in 7-10 Days
Connection Size
Connection Type
In-Stock
Ships in 7-10 Days
Shipping Info
Shipping Info
Expedited Shipping
Expedited Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • 1
    Product Q&A
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    The Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread cleanses and purifies heating and air conditioning systems. Even the smallest of air bubbles pose a long term risk to the health and effectiveness of these systems. The Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread controls this issue by automatically by forcing air bubbles to the top where they can be safely discharged automatically. The Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread has a Flow Capacity of 15.3 GPM and a CV of 56.4.
  • Caleffi 551035A Features
  • Stainless steel interior
  • Connection Type: Sweat
  • Connection Size: 1.25 Inches
Specifications
General Information
Product Line
Discal
Material
Steel
Performance
CV Value
56.4
Maximum Flow Rate
15.3 GPM
Minimum Operating Temperature
32 F
Maximum Operating Temperature
250 F
Dimensions
End 1 Connection Type
Female NPT
End 1 Connection Size
1/2 Inch
End 2 Connection Type
Sweat
End 2 Connection Size
1 1/4 Inches
Product Weight
3.7 Pounds
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Features
Features
    The Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread cleanses and purifies heating and air conditioning systems. Even the smallest of air bubbles pose a long term risk to the health and effectiveness of these systems. The Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread controls this issue by automatically by forcing air bubbles to the top where they can be safely discharged automatically. The Caleffi Discal Air Separator with 1/2" FNPT Bottom Thread has a Flow Capacity of 15.3 GPM and a CV of 56.4.
  • Caleffi 551035A Features
  • Stainless steel interior
  • Connection Type: Sweat
  • Connection Size: 1.25 Inches
Specifications
General Information
Product Line
Discal
Material
Steel
Performance
CV Value
56.4
Maximum Flow Rate
15.3 GPM
Minimum Operating Temperature
32 F
Maximum Operating Temperature
250 F
Dimensions
End 1 Connection Type
Female NPT
End 1 Connection Size
1/2 Inch
End 2 Connection Type
Sweat
End 2 Connection Size
1 1/4 Inches
Product Weight
3.7 Pounds
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Product Specs
+
Specifications
General Information
Product Line
Discal
Material
Steel
Performance
CV Value
56.4
Maximum Flow Rate
15.3 GPM
Minimum Operating Temperature
32 F
Maximum Operating Temperature
250 F
Dimensions
End 1 Connection Type
Female NPT
End 1 Connection Size
1/2 Inch
End 2 Connection Type
Sweat
End 2 Connection Size
1 1/4 Inches
Product Weight
3.7 Pounds
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Reviews
+
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Product Q&A
(1)
+
Search Product Q&A's Answered by Bob, the Heating Product Expert
icon-social-fb1
+
Should element be removed for sweating procedure?
A. Santa
from New York
March 24, 2016
Answer
Removing the element is not necessary, but you should wrap the separator in a cool wet rag before making your connections. You should also direct the flame with care to avoid overheating the air separator.
