Caleffi Air & Dirt Separator, 1" NPT Male Union Connections

Caleffi Air & Dirt Separator, 1" NPT Male Union Connections
Our Price
Compare Prices
Shipping Info
Model: 546016A
1.0 out of 51.0 out of 51.0 out of 51.0 out of 51.0 out of 5
Number of Reviews (1)
Write A Review
$174.15
Only 2 In-Stock
Ships Tuesday, Dec 11th
Holiday Shipping Schedule
Holiday Schedule -

Only 2 In-Stock
Ships Tuesday, Dec 11th
Shipping Info
Shipping Info
Expedited Shipping
Expedited Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • 1
    Reviews
  • Product Q&A
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    The Caleffi Air & Dirt Separator cleanses and purifies hot or chilled systems. Both microparticles and microbubbles pose a long term risk to the health and effectiveness of water systems. The Caleffi Air & Dirt Separator controls this issue by automatically dispersing microbubbles and forcing microparticles to the bottom of the unit where they can be safely discharged even while the system is operating. The beauty of the Caleffi Air & Dirt Separator is in that you do not need separate units, creating a simple and effective system. The Caleffi Air & Dirt Separator has a Flow Capacity of 9.3 GPM and a CV of 32.5.
  • Caleffi 546016A Features
  • Stainless steel interior
  • Collects dirt particles as small as 5 microns
  • Connection Type: NPT Union
  • Connection Size: 1 Inches
Specifications
General Information
Separator Type
No
Connection Type
NPT Union
Material
Steel
UPC
8016615336894
Performance
CV Value
32.5
Maximum Flow Rate
9.3 GPM
Minimum Operating Temperature
32 F
Maximum Operating Temperature
250 F
Dimensions
Connection Size
1 Inch
Product Weight
8.3 Pounds
Warranty Information
Parts Warranty ? A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Features
Features
    The Caleffi Air & Dirt Separator cleanses and purifies hot or chilled systems. Both microparticles and microbubbles pose a long term risk to the health and effectiveness of water systems. The Caleffi Air & Dirt Separator controls this issue by automatically dispersing microbubbles and forcing microparticles to the bottom of the unit where they can be safely discharged even while the system is operating. The beauty of the Caleffi Air & Dirt Separator is in that you do not need separate units, creating a simple and effective system. The Caleffi Air & Dirt Separator has a Flow Capacity of 9.3 GPM and a CV of 32.5.
  • Caleffi 546016A Features
  • Stainless steel interior
  • Collects dirt particles as small as 5 microns
  • Connection Type: NPT Union
  • Connection Size: 1 Inches
Specifications
General Information
Separator Type
No
Connection Type
NPT Union
Material
Steel
UPC
8016615336894
Performance
CV Value
32.5
Maximum Flow Rate
9.3 GPM
Minimum Operating Temperature
32 F
Maximum Operating Temperature
250 F
Dimensions
Connection Size
1 Inch
Product Weight
8.3 Pounds
Warranty Information
Parts Warranty ? A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Product Specs
+
Specifications
General Information
Separator Type
No
Connection Type
NPT Union
Material
Steel
UPC
8016615336894
Performance
CV Value
32.5
Maximum Flow Rate
9.3 GPM
Minimum Operating Temperature
32 F
Maximum Operating Temperature
250 F
Dimensions
Connection Size
1 Inch
Product Weight
8.3 Pounds
Warranty Information
Parts Warranty ? A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
