Amtrol Extrol - 86 Gallon - Vertical Boiler System Expansion Tank

Model:

SX-160V

Write a Review
$806.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Factory-Direct
Ships in 2-5 Business Days
synchrony card logo
$135 / Month
Suggested monthly payments with 6 month financing.
Amtrol Extrol - 86 Gallon - Vertical Boiler System Expansion Tank
Amtrol Extrol - 86 Gallon - Vertical Boiler System Expansion Tank
Model: SX-160V
$806.00
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Features

    In 1954, Amtrol invented the first expansion tank to control pressure build-up and energy consumption in heating and chilled water systems. More than 50 years later the SX is still the one of the world?s leading floor-standing expansion tanks and is proudly made in the USA! The SX vertical boiler system expansion tank collects the expanded water as system temperatures rise which reduces potentially dangerous pressure build-up. Equipped with a 100 percent tested sealed air cushion, water-tight reservoir, air stem for pre-charge adjustment, and a deep drawn steel tank, the SX is reliable and built to last. The SX-160V is ideal for large residential and light commercial applications and can be used with high output boilers.
  • USA Made
  • All SX thermal expansion tanks are made in the USA.
  • Heavy Duty Tank
  • From the deep drawn steel tank to the water-tight reservoir for expanded water, this thermal expansion tank is constructed for maximum strength and efficient energy consumption.
  • Eliminates Wasted Energy
  • Expanded water caused by thermal expansion is collected by the SX tank which returns the water back to your system which preventing faucet drips, intermittent toilet fill, and pressure relief valve discharge.
  • Protection for Your System
  • SX thermal expansion tanks are designed to protect your water heater, fixtures, and appliances by preventing dangerous pressure build up.

Specifications

SX-160V
specs product image PID-45597
General Information
Product Line
Extrol
Connection Type
NPT
UPC
642031118738
Performance
Maximum Operating Temperature
240 F
Maximum Operating Pressure
100 PSI
Dimensions
Storage Volume
86 Gallons
Maximum Acceptance Volume
46 Gallons
Connection Size
1 1/4 Inches
Product Diameter
26 Inches
Product Height
47 Inches
Product Weight
123 Pounds
Shipping Width
26 Inches
Shipping Height
47 Inches
Shipping Length
26 Inches
Shipping Weight
123 Pounds
Certifications
Country of Origin
United States
Warranty Information
Warranty Learn More
1 Year
