Amtrol Therm-X-Trol - 44 Gallon - Vertical Thermal Expansion Tank

Model:

ST-80V

Write a Review
$750.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
In-Stock
Ships in 1-2 Business Days
Shipping to60601
synchrony card logo
$125 / Month
Suggested monthly payments with 6 month financing.
Amtrol Therm-X-Trol - 44 Gallon - Vertical Thermal Expansion Tank
Amtrol Therm-X-Trol - 44 Gallon - Vertical Thermal Expansion Tank
Model: ST-80V
$750.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

    In 1954, Amtrol invented the thermal expansion tank to control pressure build-up in closed, hot water systems. Today they are continuing to roll out efficient and reliable tanks to improve your system. The ST vertical thermal expansion tank is a perfect example of this. By accepting expanded water caused by thermal expansion, the ST is able to then return the water to the system when hot water is used. The ST also prevents pressure relief valve discharge, dripping faucets, and intermittent toilet fill. From the strong deep drawn steel domes with corrosion resistant liner to the welded air charge fitting, the ST is designed to prevent damaging pressure buildup and eliminate energy and water waste. The ST-80V is ideal for large residential and light commercial applications.
  • USA Made
  • All ST thermal expansion tanks are made in the USA at facilities certified for maintaining high-quality standards.
  • Heavy Duty Tank
  • From the deep drawn steel dome with rigid polypropylene liner to the welded air charge fitting, this thermal expansion tank is constructed from top to bottom for maximum strength and corrosion resistance.
  • Eliminates Wasted Energy
  • Expanded water caused by thermal expansion is collected by the ST tank which returns the water back to your system which preventing faucet drips, intermittent toilet fill, and pressure relief valve discharge.
  • Protection for Your System
  • ST thermal expansion tanks are designed to protect your water heater, fixtures, and appliances by preventing dangerous pressure build up.
  • Adaptable
  • Multiple tanks can be installed to accommodate large systems.

Specifications

ST-80V
specs product image PID-45605
General Information
Product Line
Therm-X-Trol
Connection Type
NPT
Color
Tan
UPC
642031395726
Performance
Maximum Operating Temperature
200 F
Maximum Operating Pressure
150 PSI
Dimensions
Storage Volume
44 Gallons
Maximum Acceptance Volume
33.9 Gallons
Connection Size
1 1/4 Inches
Product Diameter
22 Inches
Product Height
36 Inches
Product Weight
224 Pounds
Shipping Width
22 Inches
Shipping Height
36 Inches
Shipping Length
22 Inches
Shipping Weight
224 Pounds
Certifications
Country of Origin
United States
Warranty Information
Warranty Learn More
1 Year
