Amtrol Extrol - 4.4 Gallon - In-Line Expansion Tank Combination Kit - 1-1/4" Purger & Vent
Amtrol Extrol - 4.4 Gallon - In-Line Expansion Tank Combination Kit - 1-1/4" Purger & Vent
+
Share This Product
-
Product Description
-
1Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Features
Features
- USA Made
- All EX thermal expansion tanks are made in the USA.
- Heavy Duty Tank
- From the deep drawn steel tank to the water-tight reservoir for expanded water, this thermal expansion tank is constructed for maximum strength and efficient energy consumption.
- Air Vent
- The included automatic air vent eliminates system air, keeping your system running smoothly.
- Air Purger
- The air purger separates air from water before sending the water into the expansion tank and air to the vent.
- Product Includes
- (1) Amtrol EX-30 Expansion Tank
- (1) Amtrol 700-C Air Vent
- (1) Amtrol 444 Air Purger
In 1954, Amtrol invented the first expansion tank to control pressure build-up and energy consumption in heating and chilled water systems. More than 50 years later the EX is still the world?s leading expansion tank and is proudly made in the USA! The EX in-line boiler system expansion tank collects the expanded water as system temperatures rise which reduces potentially dangerous pressure build-up. Ideal for residential applications, the EX is equipped with a 100 percent tested sealed air cushion, water-tight reservoir, air stem for pre-charge adjustment, and a deep drawn steel tank, all ensuring the reliability of your tank over the long haul. The EX-3000-125 also includes an air purger that separates water from air, as well as an automatic air vent that eliminates system air. This keeps your whole system running smoother, quieter, and more effectively.
Specifications
General Information
Product Line
Extrol
Connection Type
NPT
UPC
642031113528
Performance
Maximum Operating Temperature
240 F
Maximum Operating Pressure
100 PSI
Dimensions
Storage Volume
4 Gallons
Maximum Acceptance Volume
2.5 Gallons
Connection Size
1 1/4 Inches
Product Diameter
11 Inches
Product Height
16 Inches
Product Weight
26 Pounds
Shipping Width
11 Inches
Shipping Height
19 Inches
Shipping Length
11 Inches
Shipping Weight
32 Pounds
Certifications
Country of Origin
United States
Warranty Information
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
EX-30 Specifications+
444-1 Specifications+
700-30 Specifications+
