Amana 17k BTU Capacity - Packaged Terminal Air Conditioner (PTAC) - 3.5 kW Electric Heat - 230 Volt
Model:
PTC173K35AXXX
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Bob, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- Integrated Bluetooth
- Using the new Amana mobile app, control your PTAC with the touch of a button. The app simplifies set-up and configuration and features integrated Eden™ connectivity. (Eden accessories are sold separately.)
- Quiet Operation
- Redesigned to be one of the quietest PTACs Amana has ever built, it features two fan motors and an indoor tangential fan that provides quiet operation.
- Dehumidification
- With increased dehumidification capacity, you can feel comfortable in higher temperatures, helping to reduce cooling costs.
- Condensate Dispersion System
- The system draws water directly onto the outdoor coil for fast evaporation, leading to increased efficiency. Increased surface area from the coil allows more water to be evaporated even on the sides of the coils, further reducing condensate run-off.
- Compressor Lock-In
- The Compressor Lock-In feature helps to extend the life of the compressor by preventing short-cycling.
- Run Tested
- All Amana PTACs are 100% run tested at their plant, including leak checks during manufacturing as well as prior to shipment from their warehouse.
- Built-In Wireless RF Antenna
- With the DT01G DigiTenna Wireless RF now built-in, the Amana PTAC provides wireless communication with thermostats and other energy management devices.
The innovative Amana PTAC features a sleek, clean appearance with improved sound quality and Bluetooth communications. With a built-in wireless antenna for communication with thermostats, Amana PTACs deliver energy management at the touch of a button. Able to communicate with wall mounted thermostats as well as other energy management devices, Amana PTACs, combined with the Amana mobile app, provide instant access to unit settings, performance and more. The Amana PTAC is Eden™ EMS ready. Adding the complete Eden™ control system accessories (sold separately) delivers energy efficiency and wireless communication. With low EER ratings, the energy efficient Amana PTACs may qualify you for rebates offered by your electrical power company. Featuring an increased dehumidification capacity, you can maintain comfort at higher temperatures. The Compressor Lock-In feature in the Amana PTAC helps prevent short-cycling, increasing the lifespan. Backed by a five year warranty, Amana PTACs are a durable, reliable and efficient unit that will never disappoint.
Product Note
PTAC units require a wall sleeve, exterior grille and a wall thermostat for functionality. These can be found under the "Recommended Accessories" tab.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types
PTC173K35AXXX
General Information
Type
PTAC
Product Line
PTC
Product Category
PTAC Unit
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Cooling + Electric Heat
Refrigerant Type
R-410A
Performance
Cooling BTU
17000
Cooling Capacity
16400 BTU
Electric Heat Capacity
3.5 kW
Moisture Removal
3.5 Pints/Hour
Cooling Power Input
1740 Watts
Maximum Air Flow
360 CFM
Minimum Air Flow
314 CFM
Electrical Data
Plug Type
NEMA 6-20P
Voltage
230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
19.5 Amps
Recommended Breaker Size
20 Amps
Dimensions
Product Height
16 1/16 Inches
Product Width
42 Inches
Product Depth
21 1/2 Inches
Product Weight
125 Pounds
Warranty Information
Unit Replacement Warranty
1 Year
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
