Pensotti DD20.16SNG
Pensotti DD20.16SNG
Hover to zoom
1 Of 5

Pensotti DD - Single Panel Wall Radiator - 20" H x 16" W - 2,171 BTU

Model:

DD20.16SNG

Write A Review
$356.08
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
synchrony card logo
$60 / Month
Suggested monthly payments with 6 month financing.
Pensotti DD - Single Panel Wall Radiator - 20
Pensotti DD - Single Panel Wall Radiator - 20" H x 16" W - 2,171 BTU
Model: DD20.16SNG
$356.08
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Pensotti DD20.16SNG panel radiator provides the perfect combination of comfortable radiant heat with an elegant design. Perfect for homes with limited space, the DD20.16SNG features a slimmer profile than Pensotti\'s standard radiators. It is extremely versatile and can be used as the primary source of heating, a supplement to a radiant floor system, or as an addition with traditional heating sources. Unlike conventional baseboard radiators, Pensotti panel radiators emit both radiant and convective heat to achieve unsurpassed comfort and efficiency. Their durability and ease of service and install make them among the most unique panel radiators.
  • Compact Design
  • Pensotti DD panel radiators use almost 1/4th of the space taken by traditional radiators.
  • Quiet Operation
  • With virtually silent operation, Pensotti panel radiators eliminate distracting noises commonly associated with other types of heating systems.
  • Superior Heating
  • Unlike traditional radiators that only give off convective heat, Pensotti panel radiators emit both radiant and convective heat to produce efficient warmth throughout your home.
  • Simplicity and Durability
  • Pensotti DD panel radiators are simply designed to fit in with your home's décor. These radiators are built to last and reduce the areas where household dust might collect.
  • Product Includes
  • (1) Thermostatic Insert
  • (1) Air Vent
  • (1) Wall Mounting Bracket Set
  • (2) Reducers
  • (2) 1/2" Pex Fittings
  • (2) 1/2" Copper Fittings
  • (2) White Escutcheons
  • (2) White Pipe Covers
  • Product Note
    A factory installed adjustable flow setter and 1/2\" x 3/4\" BSP adapter is included.
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

DD20.16SNG
specs product image PID-95843
Overview
Product Category
Radiators
General Information
Type
Panel
Product Line
DD
Product Category
Radiators
Medium Learn More
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Connection Type
BSP
Material
Steel
Performance
Heating BTU
2000
Heating Capacity
2171 BTU
Maximum Operating Temperature
250 F
Maximum Operating Pressure
145 PSI
Dimensions
Supply Connection
1/2 Inch
Return Connection
1/2 Inch
Product Height
20 Inches
Product Width
16 Inches
Product Depth
2 5/8 Inches
Product Weight
22 Pounds
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Years
