Noritz NRC711 - 4.9 GPM at 60° F Rise - 0.89 UEF - Gas Tankless Water Heater - Direct Vent
Noritz NRC711 - 4.9 GPM at 60° F Rise - 0.89 UEF - Gas Tankless Water Heater - Direct Vent
+
Share This Product
-
Product Description
-
8Reviews
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Fuel
Location
Indoor
# of Showers
UEF
Fuel
Natural Gas
Location
Indoor
#of Showers
2.3
Uniform Energy Factor
0.89
Energy Star Rated
Yes
Features
Features
- Built for Efficiency
- The NRC711-DV-NG boasts a Uniform Energy Factor of 0.89 and a direct electronic ignition that avoids always-on pilot light installations, saving you fuel and money.
- Made with Safety in Mind
- Noritz tankless water heaters have built-in safety devices including a flame rod, thermal fuse, fan rotation detector, overheat prevention device, lightning protection device, and freeze protection device, all backed by a five-year parts warranty.
- Compact, Modern Design
- Noritz tankless water heaters are engineered to have a compact design that easily allows for indoor installation.
- Product Includes
- (5) Anchoring Screws
Noritz has been in the business of providing homes with hot water for over sixty years, and introduced the industries first electronically controlled water heater in 1981. The NRC711-DV-NG represents the culmination of the experience gained over those sixty years. The ecoTough series is Noritz breakthrough line that combines temperature stability with high-efficiency technology to produce an energy-saving unit with a low carbon footprint. These fully-modulating units are designed with commercial grade copper heat exchangers that allow for optimal performance and are backed by a 12-year heat exchanger warranty. Plus, these units are all equipped with a built-in display window and can be adjusted for high altitude installations.Product Features
Specifications
General Information
Type
Tankless Water Heater
Product Line
ecoTough
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Condensing
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Venting Category
Venting Category
Venting Category describes what type of flue material can be used in water heater installations. Category III: Stainless Steel, Category IV: ABS, PVC, CPVC, PolyPro, Stainless Steel
IV
Storage Type
Tankless
Installation Location
Indoor
Mount Type
Wall
Includes Pump
No
Gas Conversion Kit
Not Available
UPC
817000012953
Additional Model Numbers
NRC711-DV-NG, NRC711DV-NG
Performance
Maximum Input Capacity
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
157000 BTU
Minimum Input Capacity
15000 BTU
Flow Rate at 40F Temperature Rise
Flow Rate at 40F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
7.1 GPM
Flow Rate at 45F Temperature Rise
Flow Rate at 45F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
6.5 GPM
Flow Rate at 50F Temperature Rise
Flow Rate at 50F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
5.8 GPM
Flow Rate at 60F Temperature Rise
Flow Rate at 60F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
4.9 GPM
Flow Rate at 70F Temperature Rise
Flow Rate at 70F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
4.2 GPM
Uniform Energy Factor
Uniform Energy Factor
Uniform Energy Factor (UEF) is a measurement of water heater energy efficiency. The higher the energy factor, the more efficient the water heater.
0.89
Minimum Flow Rate
0.5 GPM
Ultra Low NOx Emissions
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
3/4 Inch
Condensate Drain Size
1/2 Inch
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Product Height
23 29/48 Inches
Product Width
13 19/24 Inches
Product Depth
6 17/24 Inches
Product Weight
41 Pounds
Intake Diameter
3 Inches
Exhaust Diameter
3 Inches
Certifications
CSA Listed
Yes
Energy Star Listed
Yes
AHRI Certified
Yes
NSF Certified
NSF Certified
The National Sanitation Foundation has developed public health standards and certification programs to protect the world's food, water, consumer products and environment.
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
12 Years
Fuel
Location
Indoor
# of Showers
UEF
Fuel
Natural Gas
Location
Indoor
#of Showers
2.3
Uniform Energy Factor
0.89
Energy Star Rated
Yes
Features
Features
- Built for Efficiency
- The NRC711-DV-NG boasts a Uniform Energy Factor of 0.89 and a direct electronic ignition that avoids always-on pilot light installations, saving you fuel and money.
- Made with Safety in Mind
- Noritz tankless water heaters have built-in safety devices including a flame rod, thermal fuse, fan rotation detector, overheat prevention device, lightning protection device, and freeze protection device, all backed by a five-year parts warranty.
- Compact, Modern Design
- Noritz tankless water heaters are engineered to have a compact design that easily allows for indoor installation.
- Product Includes
- (5) Anchoring Screws
Noritz has been in the business of providing homes with hot water for over sixty years, and introduced the industries first electronically controlled water heater in 1981. The NRC711-DV-NG represents the culmination of the experience gained over those sixty years. The ecoTough series is Noritz breakthrough line that combines temperature stability with high-efficiency technology to produce an energy-saving unit with a low carbon footprint. These fully-modulating units are designed with commercial grade copper heat exchangers that allow for optimal performance and are backed by a 12-year heat exchanger warranty. Plus, these units are all equipped with a built-in display window and can be adjusted for high altitude installations.Product Features
Specifications
General Information
Type
Tankless Water Heater
Product Line
ecoTough
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Condensing
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Venting Category
Venting Category
Venting Category describes what type of flue material can be used in water heater installations. Category III: Stainless Steel, Category IV: ABS, PVC, CPVC, PolyPro, Stainless Steel
IV
Storage Type
Tankless
Installation Location
Indoor
Mount Type
Wall
Includes Pump
No
Gas Conversion Kit
Not Available
UPC
817000012953
Additional Model Numbers
NRC711-DV-NG, NRC711DV-NG
Performance
Maximum Input Capacity
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
157000 BTU
Minimum Input Capacity
15000 BTU
Flow Rate at 40F Temperature Rise
Flow Rate at 40F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
7.1 GPM
Flow Rate at 45F Temperature Rise
Flow Rate at 45F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
6.5 GPM
Flow Rate at 50F Temperature Rise
Flow Rate at 50F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
5.8 GPM
Flow Rate at 60F Temperature Rise
Flow Rate at 60F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
4.9 GPM
Flow Rate at 70F Temperature Rise
Flow Rate at 70F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
4.2 GPM
Uniform Energy Factor
Uniform Energy Factor
Uniform Energy Factor (UEF) is a measurement of water heater energy efficiency. The higher the energy factor, the more efficient the water heater.
0.89
Minimum Flow Rate
0.5 GPM
Ultra Low NOx Emissions
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
Yes
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
3/4 Inch
Condensate Drain Size
1/2 Inch
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Product Height
23 29/48 Inches
Product Width
13 19/24 Inches
Product Depth
6 17/24 Inches
Product Weight
41 Pounds
Intake Diameter
3 Inches
Exhaust Diameter
3 Inches
Certifications
CSA Listed
Yes
Energy Star Listed
Yes
AHRI Certified
Yes
NSF Certified
NSF Certified
The National Sanitation Foundation has developed public health standards and certification programs to protect the world's food, water, consumer products and environment.
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
12 Years
