Features
- Mitsubishi MSZ-GE06NA-8 Wall Mounted Mini Split Indoor Units
- Mitsubishi MSZ-GE09NA-8 Wall Mounted Mini Split Indoor Units
- Mitsubishi MSZ-GE12NA-8 Wall Mounted Mini Split Indoor Units
- Mitsubishi MSZ-GE15NA-8 Wall Mounted Mini Split Indoor Units
- Mitsubishi MSZ-FE09NA-8 Wall Mounted Hyper-Heating Mini Split Indoor Units
- Mitsubishi MSZ-FE12NA-8 Wall Mounted Hyper-Heating Mini Split Indoor Units
- Mitsubishi MFZ-KA09NA Floor Standing Mini Split Indoor Units
- Mitsubishi MFZ-KA12NA Floor Standing Mini Split Indoor Units
- Mitsubishi SEZ-KD09NA4R1.TH Concealed Duct Mini Split Indoor Units
- Mitsubishi SEZ-KD12NA4R1.TH Concealed Duct Mini Split Indoor Units
- Mitsubishi SEZ-KD15NA4R1.TH Concealed Duct Mini Split Indoor Units
- Mitsubishi SLZ-KA Ceiling Cassette Mini Split Indoor Units
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing.
- Disconnect Box & Electrical Whip Kit - The Disconnect Box & Whip Kit provides a safe and simple way to connect your outdoor condenser to your fuse box.
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
- Outdoor Condenser Plastic Pad (Optional) - This pad provides an even surface, free of debris, on which to place your outdoor condenser.
- Wall Bracket (Optional) - A simple and sturdy way to mount your outdoor condenser off of the ground.
This product requires two or more compatible indoor units for functionality.
For over 50 years, Mitsubishi has remained at the forefront of the mini split industry thanks to their dedication to providing efficient, user-friendly comfort solutions. The MXZ-2B20NA-1 is an outdoor condenser for use in multi-zone mini split applications. It supports two indoor units, allowing you to create a custom zoned heating and cooling system based entirely around the specific needs of your home. With a broad range of compatible indoor units and efficiency-boosting inverter technology, the MXZ-2B20NA-1 is a smart addition for nearly any home.
Product Features
Precision Temperature Control Technology
The MXZ-2B20NA-1 outdoor condenser is equipped with inverter technology and an electronic linear expansion valve. By adjusting compressor speed and refrigerant flow, the output of the unit can be matched to the zone for precise temperature control and improved efficiency.
Mix and Match
The MXZ-2B20NA-1 is compatible with more than a dozen different indoor units, including ceiling cassette models, concealed duct models, floor standing models, and wall mounted models. This makes it easy to design a system that suits your home, no matter how it is arranged.
Product Compatible With
Product Note
This product requires two compatible Mitsubishi mini split indoor units and the following accessories for installation:
Adding these accessories to your order will provide a complete, ready-to-install mini split system.
Specifications
MXZ-2B20NA-1
General Information
Type
Outdoor Condenser
Product Line
M-Series
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Maximum Number of Zones
2
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Installation Location
Outdoor
Performance
Cooling BTU
20000
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
51 dB
Electrical Data
Phase
1
Frequency
60 Hz
Recommended Breaker Size
20 Amps
Dimensions
Maximum Line Length
164 Feet
Line Set A Liquid Connection
1/4 Inch
Line Set A Gas Connection
3/8 Inch
Line Set B Liquid Connection
1/4 Inch
Line Set B Gas Connection
3/8 Inch
Product Height
27 5/16 Inches
Product Width
33 1/16 Inches
Product Depth
13 Inches
Product Weight
130 Pounds
Certifications
ETL Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Compressor Warranty
7 Years
Reviews
(8)
Mitsubishi MXZ-2B20NA-1 Reviews & Ratings
Quiet Comfort
By Jason K.
Georgia
Purchased 08/01/2016 |
Review Posted 09/06/2016
I purchased this with four head units to help my aging heat pump and this thing is great! Out side you can't even hear it when it is running unless you are standing within a foot or two of the unit.
Hookup was easy and straight forward. I really believe that this is one of the best decisions I have made for AC in my house. When the old heat pump fails, I will put the rest of the house on this type of system.
Thanks
Hookup was easy and straight forward. I really believe that this is one of the best decisions I have made for AC in my house. When the old heat pump fails, I will put the rest of the house on this type of system.
Thanks
Jason K. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Quiet, easy installation.
By Randy Hermann
DEXTER, Michigan
Purchased 07/14/2015 |
Review Posted 07/21/2016
This was my first mini-split installation, and it was time consuming but easy. The system is very quiet while running, easily have a conversation standing next to it and I can't hear it standing around the corner of the building, 10' away. The installation is on a semi-secluded lake cottage with only nature for ambient noise, it is that quiet. The indoor units (-18 and -09 wall mounts and 2 -09? floor mounts) are also very quiet in cooling mode. I have not tested heating mode.
Notes for the installation process:
1) Keep your holes for the linesets in a straight line- it will make pulling the linesets through the joists MUCH easier.
2) Have a flaring tool available. I accidentally kinked one line and found one factory flare not as smooth as I'd like.
3) The wiring diagram at the compressor is a bit vague. Here is the order: S1 = black, S2 = white, and S3 = red. If you forget you can match it to the pattern on the indoor units.
4) DEFINITELY buy the torque wrench and some Nylog. DO NOT SKIP THE TORQUE WRENCH.
5) There are a lot of videos on how to install the system, most of them include a nitrogen pressure test. The factory instructions only use nitrogen as a bleed gas during the purge process, no need for the pressure test according to the instructions.
Notes for the installation process:
1) Keep your holes for the linesets in a straight line- it will make pulling the linesets through the joists MUCH easier.
2) Have a flaring tool available. I accidentally kinked one line and found one factory flare not as smooth as I'd like.
3) The wiring diagram at the compressor is a bit vague. Here is the order: S1 = black, S2 = white, and S3 = red. If you forget you can match it to the pattern on the indoor units.
4) DEFINITELY buy the torque wrench and some Nylog. DO NOT SKIP THE TORQUE WRENCH.
5) There are a lot of videos on how to install the system, most of them include a nitrogen pressure test. The factory instructions only use nitrogen as a bleed gas during the purge process, no need for the pressure test according to the instructions.
Randy Hermann Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Home owner
By TC Ferg
IL
Review Posted 04/13/2015
The unit I had installed is garbage does not maintain a constant heat level over runs or under runs. Should have went with conventional heat pump.
Was this review helpful?
Rating Breakdown
1/5
1/5
1/5
1/5
Silent and Efficient
By Reggie
IL
Review Posted 08/05/2014
My installer is an experienced air-con guy and I assisted him because I was curious about the whole process. This was the first mini-split system he installed and it went together easily and quickly. When we first turned it on we thought we had a problem because we couldn't hear the outdoor condenser running. After a few minutes of scratching our heads we realized that it "was" running because it was getting colder inside the house. We looked at the fan inside the condenser and it was turning and we could feel heat exhausting. The condenser is amazingly silent! And it isn't straining to cool both rooms where the indoor wall units are installed.
I ordered this unit and two MSZ-FE12NA-8 indoor wall units and they arrived quickly and in excellent condition. I highly recommend this Mitsubishi Mini Split system. Installation was a breeze and it works great and runs silently.
I ordered this unit and two MSZ-FE12NA-8 indoor wall units and they arrived quickly and in excellent condition. I highly recommend this Mitsubishi Mini Split system. Installation was a breeze and it works great and runs silently.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Owner
By Mark Z.
IL
Review Posted 05/29/2014
The Mitsubishi mxz-2b20na is a beautiful heat pump. It's well built and quite a capable unit. I'm running a total of 21,000 btus with mine, and it's quiet and handles the load easily.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
By guest
IL
Review Posted 02/07/2013
Awesome system. Had an LG before with nothing but problems.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
By
IL
Review Posted 08/15/2012
Works great. Super Quiet outdoor unit I can't hear it when its running.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
By
IL
Review Posted 07/01/2012
GREAT heating and A/C Unit..We Bought It Two Year Ago And it Works Quiet, Cool and Economical. We Have Four Inside Units and The Air Quality Is Clean and The Whole Space Is Cooled Evenly..We Are More Than Pleased With This Product
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
How-To Articles
eComfort Boosts Comfort and Energy Savings at Historic Home
Owning a historic home can be very rewarding. But those rewards come with respo...
How to Pick the Perfect Mini Split Suspended Indoor Unit
A ceiling-suspended mini split is the perfect ductless solution for large open ...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
MXZ-2B20NA-1
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Mitsubishi - 20k BTU - M-Series Outdoor Condenser - For 2 Zones
