Crown Boiler Phantom II - 112K BTU - 95% AFUE - Combi Gas Boiler - Direct Vent
Model:
PHTM2136CNG1SU
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
21
$125.89
In-Stock
$164.70
Only 2 In-Stock
Model: 3PPS-03PVCM-2PPF
$50.40
Model: PPKIT-3HC-18
Maximum Straight Run (Inches)
$342.00
Model: 170SV
$138.00
Factory-Direct
Model: 107039-02
$149.00
Factory-Direct
$100.00
Factory-Direct
$114.00
Factory-Direct
$197.00
In-Stock
Model: 44443WPR
$197.00
In-Stock
$157.00
Factory-Direct
Model: 3PPS-AD-M
$27.50
Only 1 In-Stock
$40.32
Model: 3PPS-X4L
$33.60
Model: 3PPS-R2L
$35.84
Model: 551007A
Connection Type
$161.82
Only 4 In-Stock
Model: PPKIT-3VC-42
Maximum Straight Run (Inches)
$518.00
Model: PPKIT-3HT-18
Maximum Straight Run (Inches)
$325.00
Features
- Easy Fuel Conversion
- The Phantom II is easily field converted to liquid propane with no conversion kit required.
- Guess Free Installation
- With easy access to components through removable front and side paneling and a dropdown control center, the Phantom II relieves the guess work of installation.
- Rate Based Reset
- Featuring an innovative rate based temperature reset, the Phantom II doesn't require an outdoor sensor.
- High Efficiency Heating and Hot Water
- The Crown Phantom II Combi boiler combines space heating and domestic hot water production while maintaining an impressive efficiency rating of 95% AFUE with a 10:1 turndown ratio.
- Condensing Boiler Technology
- The Phantom II boiler uses condensing technology, allowing the boiler to recover heat energy in the exhaust gas that might otherwise be expelled from your home. This is what allows the boiler to reach such high levels of efficiency.
- 10-to-1 Turndown Ratio
- The modulating burner used by the Phantom II condensing boiler can adjust its firing rate down to as low as one tenth of its maximum firing rate in response to heating requirements, further increasing the efficiency of your boiler.
- Stainless Steel Heat Exchanger
- The water tube heat exchanger is made from high grade stainless steel, giving your boiler's internals as much corrosion resistance as possible straight out of the factory while maximizing its longevity.
The Phantom II series from Crown is a high efficiency condensing boiler with domestic hot water production that comes with a multitude of features to set it apart from the competition. At its core, high efficiency condensing operation with AFUE levels up to 95% dramatically reduce your home's heating costs. The first to feature Phantom Adaptive Technology, the Phantom II series can be field converted to liquid propane with no kit required, has rate based temperature reset and easy start up. With a modulating burner with a 10-to-1 turn down ratio and self diagnotics, the boiler becomes an all-inclusive efficiency powerhouse more than worthy of a spot on your utility room's wall.
California residents see
Warning: This product can expose you to chemicals including Chromium (hexavalent compounds) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
PHTM2136CNG1SU
Overview
Product Category
Boiler
General Information
Product Line
Phantom II
Product Category
Boiler
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Heat Exchanger Material
Stainless Steel
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Combustion Type
Combustion Type
Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
Condensing
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
DHW Production
DHW Production
DHW (Domestic Hot Water) is potable water for uses other than space heat. Some boilers are able to provide DHW "out of the box", while others can do so with the purchase of optional accessories.
Yes
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Modulating
Mount Type
Wall
Minimum Altitude
0 Feet
Maximum Altitude
2000 Feet
Assembly Type
Packaged
Includes Pump
Yes
Gas Conversion Kit
Available
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
95 %
Maximum Input Capacity
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
120000 BTU
Minimum Input Capacity
13600 BTU
DOE Heating Capacity
DOE Heating Capacity
Also referred to as Gross Output, this is the output of a boiler after accounting for combustion efficiency. We recommend sizing hot water boilers based on the DOE Heating Capacity.
112000 BTU
Net I=B=R Capacity
Net I=B=R Capacity
I=B=R, also referred to as Net Output or AHRI Capacity, is the rated heat output of a boiler after accounting for combustion efficiency, piping loss, and an extra pickup factor. We recommend sizing steam boilers based on the I=B=R rating.
97000 BTU
Turndown Ratio
10:1
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
1/2 Inch
Flue Connection Size
2 Inches
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Supply Connection
1 1/4 Inches
Return Connection
1 1/4 Inches
Product Height
29 7/8 Inches
Product Width
18 Inches
Product Depth
16 5/8 Inches
Shipping Weight
112 Pounds
Certifications
Energy Star Listed
Yes
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
205301567
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
12 Years
