Crown Boiler MT040GBR - 40 Gal. - Indirect Water Heater



Write A Review
Free Shipping
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Ships in 2-3 Weeks
synchrony card logo
$327 / Month
Suggested monthly payments with 6 month financing.
Crown Boiler MT040GBR - 40 Gal. - Indirect Water Heater
Crown Boiler MT040GBR - 40 Gal. - Indirect Water Heater
Model: MT040GBR
Product Q&A
How-To Articles

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10


    The Maxi-Therm indirect fired hot water heater from Crown is designed from the ground up to maximize longevity in every way possible. Both the tank and the internal coil are coated with a porcelain enamel, preventing corrosive materials in a home\\\'s water supply from reacting with the metals within the water heater. The tank also contains three sacrificial anode rods, reactive rods that descend into the tank and neutralize corrosives before they have a chance to damage your water heater. Combined with two inches of CFC-free foam insulation all around the tank, the Maxi-Therm is an ideal long term water heater solution.
  • Two Inch Thick Insulation Layer
  • Crown's Maxi-Therm heaters are lined with a two inch thick layer of insulation, keeping the water in your water heater hot for hours on end during standby periods.
  • Rugged Steel Tank
  • The outer shell of the Maxi-Therm tank is constructed from high grade steel, a material proven in thousands of installations to be durable and efficient.
  • Three Sacrificial Anode Rods
  • The Maxi-Therm water heater comes with three replaceable sacrificial anode rods, dramatically increasing the longevity of the water heater by removing corrosive materials before they can cause damage..
  • Porcelain Enamel Coated Coil
  • The coil on the inside of the Maxi-Therm water heater is coated with a porcelain enamel, working with the anode rods to prevent corrosion.
California residents see
Warning: This product can expose you to chemicals including Chromium (hexavalent compounds) which is known to the State of California to cause Cancer.
For more information go to:


specs product image PID-50214
Product Category
Water Heater - Indirect-Fired
General Information
Indirect Water Heater
Product Line
Maxi-Therm 2
Product Category
Water Heater - Indirect-Fired
Medium Learn More
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Coils Quantity
Connection Type
Mount Type
Stainless Steel
First Hour Delivery Learn More
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
188 Gallons
Continuous Recovery Rate
162 Gallons
Electrical Data
120 Volts
60 Hz
Storage Volume
40 Gallons
Cold Water Inlet
1 Inch
Hot Water Outlet
1 Inch
Supply Connection
3/4 Inch
Return Connection
3/4 Inch
Product Diameter
24 Inches
Product Height
36 3/4 Inches
Product Width
24 Inches
Product Depth
24 Inches
Shipping Weight
168 Pounds
Country of Origin
United States
ETL Listed
AHRI Certified
Warranty Information
Vessel Warranty
10 Years
