Features
- Smooth-Surface Stainless Steel Coil
- The Mega-Stor line of indirect fired water heaters comes with a stainless steel coil with a larger than normal surface area. This translates to a dramatically increased recovery rate, allowing you to enjoy a hot shower for much longer.
- Two Inch Thick Insulation Layer
- Crown's Mega-Stor heaters are lined with a two inch thick layer of insulation, keeping the water in your water heater hot for hours on end during standby periods.
- Rugged Stainless Steel Tank
- The outer shell of the Mega-Stor tank is constructed from high grade stainless steel, TIG welded and passivated for durability and longevity.
- Lifetime Warranty
- All Crown Mega-Stor water heaters include a limited lifetime warranty after registration.
Crown's Mega-Stor 2 indirect fired hot water heaters are a perfect complement to a Crown boiler, providing enough hot water to satisfy an entire family's hot water needs. The tank is lined with two inch thick polystyrene insulation, to keep water hot for hours. The stainless steel outer shell provides years of structural integrity. The coil itself is made from smooth surfaced stainless steel, maximizing heat transfer for a quick recovery rate. For any home heated by a boiler, the Mega-Stor 2 is the best option for quick and efficient hot water production.
California residents see
Warning: This product can expose you to chemicals including Chromium (hexavalent compounds) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
MS2-119
Overview
Product Category
Water Heater - Indirect-Fired
UPC
645504508647
General Information
Type
Indirect Water Heater
Product Line
Mega-Stor II
Product Category
Water Heater - Indirect-Fired
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
1
Application
Residential
Connection Type
NPT
Mount Type
Floor
Material
Stainless Steel
Capacity
111.3 Gallons
Performance
First Hour Delivery
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
497 Gallons
Continuous Recovery Rate
417 Gallons
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Cold Water Inlet
1 1/4 Inches
Hot Water Outlet
1 1/4 Inches
Supply Connection
1 1/4 Inches
Return Connection
1 1/4 Inches
Product Diameter
30 3/4 Inches
Product Height
62 7/8 Inches
Product Width
23 1/2 Inches
Product Depth
23 1/2 Inches
Product Weight
251 Pounds
Shipping Weight
261 Pounds
Certifications
Country of Origin
United States
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
9008525
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
Lifetime Limited Years
