                    Amana 12k BTU Capacity - Packaged Terminal Air Conditioner (PTAC) - Heat Pump - 3.7 kW Electric Heat - 265 Volt - R-32
Model:





                                                PTH124J35AXXX
        +
        Share This Product


Recommended Accessories
                                Expert Recommended Accessories
                                Selected by Ken, our Expert


                        Required Accessories
                        3

                    These accessories are required to properly setup/install this product.
                    Model: SGK01B
$40.00
In-Stock
$201.00
In-Stock
$115.00
In-Stock
                        Optional Accessories
                        1

                    Model: EB-STATE6LP-01
$199.99
In-Stock
Features
- Integrated Bluetooth
 - Using the new Amana mobile app, control your PTAC with the touch of a button. The app simplifies set-up and configuration and features integrated Eden™ connectivity. (Eden accessories are sold separately.)
 - Quiet Operation
 - Redesigned to be one of the quietest PTACs Amana has ever built, it features two fan motors and an indoor tangential fan that provides quiet operation.
 - Dehumidification
 - With increased dehumidification capacity, you can feel comfortable in higher temperatures, helping to reduce cooling costs.
 - Condensate Dispersion System
 - The system draws water directly onto the outdoor coil for fast evaporation, leading to increased efficiency. Increased surface area from the coil allows more water to be evaporated even on the sides of the coils, further reducing condensate run-off.
 - Compressor Lock-In
 - The Compressor Lock-In feature helps to extend the life of the compressor by preventing short-cycling.
 - Emergency Heat
 - Amana PTAC Heat Pump units automatically switch to electric resistance heat if the heating load is greater than the unit's capacity or if there is a compressor system failure.
 - Run Tested
 - All Amana PTACs are 100% run tested at their plant, including leak checks during manufacturing as well as prior to shipment from their warehouse.
 - Built-In Wireless RF Antenna
 - With the DT01G DigiTenna Wireless RF now built-in, the Amana PTAC provides wireless communication with thermostats and other energy management devices.
 - The state of California requires 10.8 EER and 2.9 COP when replacing your PTAC. In new construction applications, the state of California requires 14 EER and 3.7 COP.

The innovative Amana PTAC features a sleek, clean appearance with improved sound quality and Bluetooth communications. With a built-in wireless antenna for communication with thermostats, Amana PTACs deliver energy management at the touch of a button. Able to communicate with wall mounted thermostats as well as other energy management devices, Amana PTACs, combined with the Amana mobile app, provide instant access to unit settings, performance and more. The Amana PTAC is Eden™ EMS ready. Adding the complete Eden™ control system accessories (sold separately) delivers energy efficiency and wireless communication. With low EER ratings, the energy efficient Amana PTACs may qualify you for rebates offered by your electrical power company. Featuring an increased dehumidification capacity, you can maintain comfort at higher temperatures. The Compressor Lock-In feature in the Amana PTAC helps prevent short-cycling, increasing the lifespan. Backed by a five year warranty, Amana PTACs are a durable, reliable and efficient unit that will never disappoint.
Product Note
PTAC units require a wall sleeve and exterior grille for functionality. These can be found under the "Recommended Accessories" tab.
California residents see
                        WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
 For more information go to: www.p65Warnings.ca.gov
                Specifications
PTH124J35AXXX

General Information
Type
PTAC
Product Line
PTH
Product Category
PTAC Unit
Operating Mode




            Operating Mode
            Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements.  Learn More


Heat Pump + Electric Heat
Refrigerant Type
R-32
DOE Regional Compliance




            DOE Regional Compliance
            In 2015, the US Department of Energy broke the country into three regions - North, Southeast, and Southwest - and set legal standards for energy efficiency within each region. Learn More


Nationwide
UPC
663051671515
Performance
Cooling BTU
12000
Cooling Capacity
12000 BTU
Electric Heat Capacity
3.7 kW
EER




            EER
            EER (Energy Efficiency Ratio) is a measurement of cooling efficiency under fixed conditions. It is useful for comparing units that will operate consistently under one set of conditions (e.g. server room). The higher the EER, the more efficient the system. Learn More


11.3
Maximum Air Flow
360 CFM
Minimum Air Flow
314 CFM
COP




            COP
            Coefficient of performance or COP is a rating that indicates a system's heating efficiency. The higher the COP, the more efficiently the system heats.


3.3
Electrical Data
Plug Type
NEMA 7-20P
Voltage
265 Volts
Phase
1
Frequency
60 Hz
Dimensions
Product Height
16 1/16 Inches
Product Width
42 Inches
Product Depth
21 1/2 Inches
Product Weight
125 Pounds
Warranty Information
Unit Replacement Warranty
1 Year
Parts Warranty




            Parts Warranty
            A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More


5 Years
