A.O. Smith - 66 Gal. Storage - 80 Gal. First Hour Delivery 3.17 EF Heat Pump Water Heater

Model:

FPTU-66

Write a Review
$1,649.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Monday, Mar 1st
Shipping to60601
Shipping Details
  • Lift Gate Service Available - Free Lift Gate Learn More
*We currently CANNOT ship this product to Canada or any destination outside of the United States
$275 / Month
Suggested monthly payments with 6 month financing.
Available Add-Ons
FREE
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
A.O. Smith - 66 Gal. Storage - 80 Gal. First Hour Delivery 3.17 EF Heat Pump Water Heater
A.O. Smith - 66 Gal. Storage - 80 Gal. First Hour Delivery 3.17 EF Heat Pump Water Heater
Model: FPTU-66
$1,649.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
    A.O. Smith continues to lead the way in residential and commercial water heating with close to 70 years of innovative hot water solutions. The FPTU-66 features A.O. Smith's latest high efficiency electric water heating technology. By using an electric heat pump rather than resistive heating elements the FHPT line offers money saving efficiency while also dehumidifying and cooling ambient air. A 66 gallon tank and multiple operating modes allows the unit to fit nearly any domestic hot water need. Additional quality of life features such as backup electric elements, and a Coreguard anode rod keep the FPTU-66 running reliably and efficiently even in periods of high demand.
  • Efficient Electric Hot Water
  • The A.O. Smith Voltex line heats water with a high efficiency electric heat pump rather than conventional electric methods. This provides efficient hot water while also helping to dehumidify and cool the ambient air around the unit.
  • Multiple Operating Modes
  • The FPTU-66 comes with 3 different operating modes: Efficiency, Hybrid, and Electric, to meet any and all hot water needs. Hybrid mode automatically adjusts between the compressor and heating element. Vacation mode reduces costs for up to 99 days.
  • Coreguard Anode Rod
  • The stainless steel anode rod core helps extend the life of the heater by protecting it from the corrosive effects of hot water. Coreguard technology helps to extend the life more than that of a standard rod.
  • User-Friendly Electronic Interface
  • A built-in easy to read controller on the unit gives you easy access to temperature settings, operating mode, and multiple diagnostics to make sure your unit is running exactly how you want it.
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

FPTU-66
General Information
Type
Hybrid Electric Water Heater
Product Line
Voltex
Medium Learn More
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Storage Type
Tank
Mount Type
Floor
UPC
671657246327
Performance
First Hour Delivery Learn More
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
80 Gallons
Energy Factor Learn More
Energy Factor
Energy Factor (EF) is a measurement of water heater energy efficiency. The higher the energy factor, the more efficient the water heater. Learn More
3.17
Electrical Data
Voltage
208/240 Volts
Phase
1
Frequency
60 Hz
Recommended Breaker Size
30 Amps
Current Draw
18.75 Amps
Dimensions
Storage Volume
66 Gallons
Cold Water Inlet
3/4 Inch
Hot Water Outlet
3/4 Inch
Product Height
61 Inches
Product Width
27 Inches
Product Depth
27 Inches
Product Weight
248 Pounds
Shipping Weight
289 Pounds
Certifications
Energy Star Listed
Yes
UL Listed
Yes
CSA Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
8177891
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
6 Years
