Rheem WH1P1817STANJA
Rheem WH1P1817STANJA
Hover to zoom
1 Of 5

WeatherKing By Rheem WH1P - 1.5 Ton - Air Handler - Multi-Position - PSC Motor

Model:

WH1P1817STANJA

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
WeatherKing By Rheem WH1P - 1.5 Ton - Air Handler - Multi-Position - PSC Motor
WeatherKing By Rheem WH1P - 1.5 Ton - Air Handler - Multi-Position - PSC Motor
Model: WH1P1817STANJA
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Reliability, functionality, efficiency - these are values that Rheem holds to the highest standards in the WeatherKing line of HVAC systems. The WeatherKing WH1P is a versatile 4-way convertible air handler suitable for upflow, downflow, left, and right applications. The WH1P features a foil insulated cabinet to retain desired temperature and dampen sound. The air handler's evaporator coil is designed with aluminum fins bonded to internally grooved aluminum tubing for enhanced heat transfer. The evaporator coil also aids in humidity control for additional home comfort. The WH1P features a high-grade condensate drain pan to run smoothly and ensure durability.
  • Quiet, Efficient Operation
  • Designed with a sturdy steel cabinet and foil faced insulation, the WeatherKing WH1P operates with minimal noise and maximum efficiency.
  • Humidity Control
  • The WH1P's adjustable airflow allows you to control the amount of humidity in your home.
  • Powerful Performance
  • The WH1P features a factory-installed cooling coil for improved humidity and temperature control. The coil's laced fin design allows for improved energy efficiency and system performance.
  • Built to Last
  • A high-grade drain pan fitted in the WH1P provides reliable operation, while the corrosion-resistant aluminum endplates keep the air handler looking in tip-top shape over the years.
  • TXV Valve
  • An included thermal expansion valve provides accurate refrigerant flow, so you can always get the most out of your comfort system.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

WH1P1817STANJA
specs product image PID-93977
Overview
Product Category
Air Handler
UPC
662021413865
General Information
Type
Air Handler
Product Line
WeatherKing
Product Sub-line
WH1P
Product Category
Air Handler
Refrigerant Type
R-410A
Blower Motor Type
Multi-Speed
Motor Type
PSC
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Multi-Position
Electric Heat
Available
Performance
Capacity Learn More
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
1.5 Tons
Cooling BTU
18000
Maximum Air Flow
800 CFM
Minimum Air Flow
600 CFM
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
3 Amps
Recommended Breaker Size
15 Amps
Dimensions
Suction Connection Size
3/4 Inch
Liquid Connection Size
3/8 Inch
Product Height
42 1/2 Inches
Product Width
17 1/2 Inches
Product Depth
21 11/16 Inches
Product Weight
95 Pounds
Shipping Weight
105 Pounds
Certifications
UL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
