Reznor UDBS-400 High Static Gas Fired Unit Heater - Separated Combustion - NG - 316 SS Heat Exchanger- 115/1/60 - 400,000 BTU

Model:

UDBS-400-AC4-AK1

Write a Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Reznor  UDBS-400 High Static Gas Fired Unit Heater - Separated Combustion - NG - 316 SS Heat Exchanger- 115/1/60 - 400,000 BTU
Reznor UDBS-400 High Static Gas Fired Unit Heater - Separated Combustion - NG - 316 SS Heat Exchanger- 115/1/60 - 400,000 BTU
Model: UDBS-400-AC4-AK1
Product Discontinued
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

    Reznor UDBS-400-AC4-AK1 High Static Gas Fired Unit Heater is a 115 volt, gas fired high static unit heater designed to provide efficient heating. Reznor UDBS-400-AC4-AK1 is certified for commercial and industrial use to provide a 400000 BTU/hr. output with an 82-83% thermal efficiency. Vibration isolated venter motors reduce operating noise. UDBS-400-AC4-AK1 provides a 45-75 F rise range. UDBS models use an integrated circuit board with diagnostic indicator lights to control heater operation. External gas connection allows for easy gas service connection. Reznor UDBS-400-AC4-AK1 is designed to be suspended from 4 suspension points. UDBS-400-AC4-AK1 provides improved efficiency and easier installation over previous Reznor models.
  • Reznor UDBS-400-AC4-AK1 Features
  • Certified for commercial/industrial heating
  • Titanium stabilized stainless heat exchanger
  • Multi-try direct spark ignition with 100% lockout
  • Vibration isolated venter motors
  • 4-pt suspension
  • Adjustable belt drive blower
  • Product Note
    The image may not reflect actual product features. The Reznor UDBS-400 comes with ten horizontal louvers.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

UDBS-400-AC4-AK1
specs product image PID-47382
General Information
Product Line
UDBS
Heat Exchanger Material
Stainless Steel
Fuel Type Learn More
Natural Gas
Vent Type Learn More
Direct Vent
Configuration Learn More
Horizontal
Mount Type
Suspended
Performance
Heating Capacity
328000 BTU
Maximum Input Capacity Learn More
400000 BTU
Thermal Efficiency
82 %
Maximum Air Flow
6185 CFM
Minimum Air Flow
4100 CFM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Dimensions
Flue Connection Size
6 Inches
Gas Connection Size
3/4 Inch
Product Height
42 5/8 Inches
Product Width
40 7/8 Inches
Product Depth
63 7/16 Inches
Product Weight
425 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
ANSI Certified
Yes
Warranty Information
Parts Warranty Learn More
1 Year
