Reznor UDBS-200 High Static Gas Fired Unit Heater - Separated Combustion - NG - 409 SS Heat Exchanger- 208/1/60 - 200,000 BTU
Model: UDBS-200-AC2-AK2
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews(3)
Write a Review
$4,395.56
Was $4,626.91
Free Shipping
&
Lift Gate
Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 3-4 Weeks
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Lift Gate Service Available - Free Lift Gate Learn More
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Heat Exchanger Material
Voltage / Phase
Available Add-Ons
FREE
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Share
  • Product Description
  • 3
    Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
    Reznor UDBS-200-AC2-AK2 High Static Gas Fired Unit Heater is a 208 volt, gas fired high static unit heater designed to provide efficient heating. Reznor UDBS-200-AC2-AK2 is certified for commercial and industrial use to provide a 200000 BTU/hr. output with an 82-83% thermal efficiency. Vibration isolated venter motors reduce operating noise. UDBS-200-AC2-AK2 provides a 45-75 F rise range. UDBS models use an integrated circuit board with diagnostic indicator lights to control heater operation. External gas connection allows for easy gas service connection. Reznor UDBS-200-AC2-AK2 is designed to be suspended from 4 suspension points. UDBS-200-AC2-AK2 provides improved efficiency and easier installation over previous Reznor models.
  • Reznor UDBS-200-AC2-AK2 Features
  • Certified for commercial/industrial heating
  • Titanium stabilized stainless heat exchanger
  • Multi-try direct spark ignition with 100% lockout
  • Vibration isolated venter motors
  • 4-pt suspension
  • Adjustable belt drive blower
  • Product Note
    The image may not reflect actual product features. The Reznor UDBS-200 comes with five horizontal louvers.
Specifications
General Information
Product Line
UDBS
Heat Exchanger Material
Stainless Steel
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Horizontal
Performance
Heating Capacity
166000 BTU
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
200000 BTU
Efficiency
83 %
Maximum Air Flow
3416 CFM
Minimum Air Flow
2049 CFM
Electrical Data
Voltage
208 Volts
Phase
1
Frequency
60 Hz
Dimensions
Flue Connection Size
5 Inches
Gas Connection Size
1/2 Inch
Product Height
30 9/16 Inches
Product Width
38 1/8 Inches
Product Depth
60 1/8 Inches
Product Weight
275 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
ANSI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Features
Features
    Reznor UDBS-200-AC2-AK2 High Static Gas Fired Unit Heater is a 208 volt, gas fired high static unit heater designed to provide efficient heating. Reznor UDBS-200-AC2-AK2 is certified for commercial and industrial use to provide a 200000 BTU/hr. output with an 82-83% thermal efficiency. Vibration isolated venter motors reduce operating noise. UDBS-200-AC2-AK2 provides a 45-75 F rise range. UDBS models use an integrated circuit board with diagnostic indicator lights to control heater operation. External gas connection allows for easy gas service connection. Reznor UDBS-200-AC2-AK2 is designed to be suspended from 4 suspension points. UDBS-200-AC2-AK2 provides improved efficiency and easier installation over previous Reznor models.
  • Reznor UDBS-200-AC2-AK2 Features
  • Certified for commercial/industrial heating
  • Titanium stabilized stainless heat exchanger
  • Multi-try direct spark ignition with 100% lockout
  • Vibration isolated venter motors
  • 4-pt suspension
  • Adjustable belt drive blower
  • Product Note
    The image may not reflect actual product features. The Reznor UDBS-200 comes with five horizontal louvers.
