Reznor UDBP-175 Power Vented High Static Gas Fired Unit Heater - NG - 316 Stainless Steel Heat Exchanger - 230/3/60 - 175,000 BTU

Model:

UDBP-175-AC4-AK6

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Reznor UDBP-175 Power Vented High Static Gas Fired Unit Heater - NG - 316 Stainless Steel Heat Exchanger - 230/3/60 - 175,000 BTU
Reznor UDBP-175 Power Vented High Static Gas Fired Unit Heater - NG - 316 Stainless Steel Heat Exchanger - 230/3/60 - 175,000 BTU
Model: UDBP-175-AC4-AK6
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Reznor UDBP-175-AC4-AK6 High Static Gas Fired Unit Heater is a 230 volt, gas fired high static unit heater designed to provide efficient heating. Reznor UDBP-175-AC4-AK6 is certified for commercial and industrial use to provide a 175000 BTU/hr. output with an 82-83% thermal efficiency. Vibration isolated venter motors reduce operating noise. UDBP-175-AC4-AK6 provides a 45-75 F rise range. UDBP models use an integrated circuit board with diagnostic indicator lights to control heater operation. External gas connection allows for easy gas service connection. Reznor UDBP-175-AC4-AK6 is designed to be suspended from 4 suspension points. UDBP-175-AC4-AK6 provides improved efficiency and easier installation over previous Reznor models.
  • Reznor UDBP-175-AC4-AK6 Features
  • Certified for commercial/industrial heating
  • Titanium stabilized stainless heat exchanger
  • Multi-try direct spark ignition with 100% lockout
  • Vibration isolated venter motors
  • 4-pt suspension
  • Product Note
    The image may not reflect actual product features. The Reznor UDBP-175 comes with five horizontal louvers.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

UDBP-175-AC4-AK6
specs product image PID-47078
General Information
Product Line
UDBP
Heat Exchanger Material
Stainless Steel
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Power Vent
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Horizontal
Mount Type
Suspended
Additional Model Numbers

UDBP-175-AC4-AK6, UDBP-175-AC4-AK6

Performance
Heating Capacity
145000 BTU
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
175000 BTU
Thermal Efficiency
83 %
Maximum Air Flow
2989 CFM
Minimum Air Flow
1793 CFM
Electrical Data
Voltage
230 Volts
Phase
3
Frequency
60 Hz
Dimensions
Flue Connection Size
5 Inches
Gas Connection Size
1/2 Inch
Product Height
30 9/16 Inches
Product Width
38 1/8 Inches
Product Depth
60 1/8 Inches
Product Weight
265 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
ANSI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Heat Exchanger Warranty
10 Years
