Revolv VMC - 50,000 BTU - Gas Furnace - Manufactured Home - NG - 95% AFUE - Single-Stage - Downflow - Multi-Speed

Model:

VMC1-50D36N

Write a Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Revolv VMC - 50,000 BTU - Gas Furnace - Manufactured Home - NG - 95% AFUE - Single-Stage - Downflow - Multi-Speed
Revolv VMC - 50,000 BTU - Gas Furnace - Manufactured Home - NG - 95% AFUE - Single-Stage - Downflow - Multi-Speed
Model: VMC1-50D36N
Was $1,999.00
Product Discontinued
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

    Revolv, a division of Coleman, is dedicated to bringing efficient comfort to the manufactured and mobile home market. The VMC is an incredibly efficient gas-fired furnace designed specifically for installation in manufactured homes. With a 95% AFUE rating, you can be sure that the VMC is making the most of your energy dollar. It utilizes sealed combustion, venting and drawing combustion air directly from outside your home and requires 0" clearance to combustibles on the back, sides, and top. A depth of just over two feet, a width of only 18", and a simple installation process mean that it's easy to integrate a VMC into your manufactured home and enjoy efficient comfort.
  • Field Convertible
  • All VMC furnaces are field convertible to liquid propane. A conversion plate and orifice are included with the gas valve, so that conversion can be handled during installation without requiring any additional parts.
  • Multi-Speed
  • The VMC1-50D36N uses a timed four-speed direct drive motor for the blower, giving you excellent airflow that can be scaled to your application.
  • Dual Heat Exchanger Design
  • The primary exchanger employs an aluminum coating for optimal heat transfer. The secondary heat exchanger is made from stainless steel, giving it durability, corrosion-resistance, and a long life span.
  • Advanced Ignition System
  • The combination of a slow-opening gas valve and a silicon nitride igniter give the VMC1-50D36N an ignition process that is quiet and reliable.
  • Easily Accessible
  • Accessing the vent pipes and internal components of the VMC gas-fired manufactured home furnace is a breeze. A two-piece top makes installing and maintaining your equipment easy.
  • Internal Filtration
  • The VMC doesn't just keep your home comfortable, it also keeps you air clean. A return air filter that captures dust, lint, and other contaminants is installed inside the door of the furnace where it are easy to check and replace.
  • Product Includes
  • (1) Revolv VMC1-50D36N Gas-Fired Furnace
  • (1) Liquid Propane Conversion Kit
  • (1) Filter
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

VMC1-50D36N
General Information
Type
Gas Furnace
Product Line
VMC
Fuel Type Learn More
Natural Gas
Vent Type Learn More
Direct Vent
Modulating/Staging Learn More
Single Stage
Blower Motor
ECM Multi-Speed
Configuration Learn More
Downflow
Gas Conversion Kit
Included
Performance
AFUE Learn More
95 %
Heating BTU
50000
High Fire Input
50000 BTU
High Fire Output
48000 BTU
Maximum Air Flow
1283 CFM
Minimum Air Flow
773 CFM
Ultra Low NOx Emissions Learn More
No
Low NOx Emissions Learn More
No
Electrical Data
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
7.15 Amps
Recommended Breaker Size
15 Amps
Dimensions
Flue Connection Size
2 Inches
Product Height
76 1/8 Inches
Product Width
18 3/4 Inches
Product Depth
25 3/4 Inches
Product Weight
205 Pounds
Shipping Weight
215 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
7038135
Warranty Information
Parts Warranty Learn More
5 Years
Heat Exchanger Warranty
Limited Lifetime Years

Reviews

(3)
Revolv VMC1-50D36N Reviews & Ratings

Recommended Accessories

Expert Recommended Accessories Selected by Bob, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

How-To Articles

How Gas Furnaces Work
On a cold winter's day, there's nothing like watching the snowflakes fall from ...
Choosing Between a Furnace and a Heat Pump
The battle between furnaces and heat pumps is hot right now. Although most Amer...
How to Pick the Perfect Furnace
In most cold climates, forced air heating has replaced steam and hot water syst...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts

Manuals


Media Gallery
Revolv VMC - 50,000 BTU - Gas Furnace - Manufactured Home - NG - 95% AFUE - Single-Stage - Downflow - Multi-Speed
